Home > Products > Finish paper machine > Cradle rolls for steel sheets
Cradle rolls for steel sheets
- 100 Piece / Pieces per Month
- qingdao
Product Details
Standard: | AISI | Place of Origin: | Shandong, China | Brand Name: | DAXING |
Model Number: | A | Type: | Steel Plate | Technique: | Hot Rolled |
Surface Treatment: | Coated | Application: | Container Plate | Special Use: | Silicon Steel |
Packaging Details
wood box or steel box
Product Description
Specifications
Cradle rolls for steel sheets1:high quality
2:good price
Cradle rolls for steel sheets
Specifications
1.D80~D900mm
2.C35E,C45E,100Cr6,SAE52100,etc.
3.Induction Hardening
ld rolling
5.High quality and performance
Henan Zhongyuan Roller Shaft Co., Ltd. is a professional manufacturer which mainly produces forged rolls and forged shafts fully in accordance with customers’ requirement in zhongyuan area in China. Annual intergration producing capacity is: 10000 tons of forged cold rolls, 10000tons of shafts and mechanical parts. These products have the properties of high purity, low [P],[S],[O] [H]content, less inclusions, homogeneous carbide spread, high stability and long fatigue lift. We are selling a lot of products abroad as well as domestic. We have exported to USA, Japan, Germany, U.K., India, Netherlands, Italy, Pakistan, Turkey, Etc... Roughly specification of forged rolls as follows:
1 Range:Forged rolls (weight≤50tons)
Name | Specification | Material |
Work Roll | Dia. 60~ Dia. 1000mm | 9Cr2Mo, 86CrMoV7,MC3,MC5,etc. |
Back Up Roll | Dia. 240~ Dia. 1500mm | 9Cr2Mo, MC3,MC5,etc. |
Intermediate Roll | ≤Dia. 1000mm | 9Cr2Mo, 86CrMoV7,MC3, etc. |
Leveling Roll | Dia. 60~ Dia.1000mm | 60CrMoV, H13, 80CrMoV, etc |
Table Roll | Dia. 100~ Dia. 1000mm | 1035, 1045, C35E, C40E, C45E, etc |
Pinch Roll | Dia. 80~ Dia. 1000mm | 1035, 1045, C35E, C40E, C45E, etc |
Driving Roll | Dia. 80~ Dia. 1000mm | 1035, 1045, C35E, C40E, C45E, etc |
Cradle Roll | Dia. 80~ Dia. 1000mm | 1035, 1045, C35E, C40E, C45E, etc |
Guide Roll | Dia. 80~ Dia. 1000mm | 1035, 1045, 4150, 4340, 4140, etc |
Piercing Roll | Dia. 80~ Dia. 1000mm | 1035, 1045, 4150, 4340, 4140, etc |
Straightening Roll | Dia. 80~Dia. 900mm | H13,4140,4340,EN9,EN19,EN24,EN31,51200,etc |
2 Material:H13,4130,4140,4150,4340,1035,1045,EN9,EN19,EN24,EN31,51200,SUJ2,100Cr6,K310,34CrNiMo6,36CrNiMo4,42CrMo4,86CrMoV7,Cr 2%, Cr3%, Cr 5%, etc.
3 Surface Hardness:max 100 HSD
4 Ultrasonic Test:Sep 1921-84 - Test Group 3 Class D or ASTM A388 – FBH max 4mm
5 Forging reduction ratio:≥4
6 Manufacturing process:steel ingot→forging→rough machining→QT→2th rough machining→induction quenching→finishing machining→packing→delivery
7 Quality required:Surface defect and decarburization shall be free. All dimensions are 100% OK.
8 Marking:Heat Number, Order Number, Made in China on bar end
9 Packing:wooden box or metal pallet for protection against rust and damage.
Company Profile
![](http://res.goldsupplier.com/3/1_570_27060_480_360.jpg)
Shandong Zhangqiu Daxing Paper-making Machinery Co., Ltd. Has a research and development, production and processing, sales management, technical services as one of the paper machine roller of professional manufacturers.
Our company has years' production experience and strong technical force including 66 engineers and 316 employees, and its fixed assets have amounted to 26 million yuan. It has 58 sets of professional production and testing equipment and four sets of large processing equipment with the working range of dia2000*10000. We boast fine equipment, sound quality guarantee system, complete detection means and technological equipment. Through the ISO9001 international quality system certification.Our products include papermaking glue roll (press roll, touch roll, sizing roll), copper roll (chest roll), chrome-plated roll, glass steel roll, steel roll, textile roll, printing roll, and dyeing roll. Our products are sold to all over the world, such as the USA, Germany, Japan, Russia, Indonesia, India, Bangladesh, and Pakistan.
Since its inception, the spirit of "quality first, customer the best return," the purpose, we produced the "daxing" brand products to the best quality, lowest price, best service to win the majority of users ages.
