High Precision XK718 CNC Milling Machine
US$ 69,230 - 76,900
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
JZ
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Jiangsu, China
Brand Name
JZ
Model Number
XK718
Type
Universal
CNC or Not
CNC
Power(W)
15KW
Dimension(L*W*H)
4200*2350*3200
Weight
13500kg
Certification
ISO CE
Warranty
1 Year
high precision XK718 CNC Milling Machine
Technical Date
| Items/Types | XK718 |
| Worktable Size | 800×1700mm |
| Worktable T-grooves | 5-22 |
| Travel(X,Y,Z) | 1500×800×700mm |
| Distance between Spindle&Worktable | 170-870mm |
| Distance between Spindle Center&Z-axis Guidewheel Surface | 800mm |
| Taper of Spindle | BT50 |
| Max. PRM of Spindle | 6000rpm |
| Motor Power of Spindle | 15kW |
| Feeding Rate(related to control system) | 1-5000mm/min |
| Positioning Accuracy | ±0.01mm |
| Repeated Positioning Accuracy | ±0.005mm |
| Machine Weight | 13500kg |
| Overall Dimensions | 4420×2350×3200mm |
| Worktable Loading Capacity | 1500kg |
The CNC milling machine has the following advantages:
good rigidity, high precision, low noise, reasonable price and easy to operate and maintain.
It can automatically mill planes, grooves, inclined planes and various complex curved surfaces and drilling, reaming,etc.
The machine tool has a large range of applications, wide applicability and superior performance.
It is especially suitable for mold processing.
Packing and Delivery
Packaging details:wooden container
Delivery detail:shipped in 20-40days after payment
Sample picture
FAQ
| 1..Do you provide samples? |
| No |
| 2.Could your engineers go to our factory to install the machine and train our workers? |
| Yes,our engineers cuold go to your factory and assist you. |
| 3.Are you manufacturer? |
|
Yes,we are manufacturer.We have our technical team
|
