daikin VRV-X The IntelliSense 3D airflow duct air conditioner
1.mute operations:22dB
2.CE,ISO 9001 certificate
pany onsite checked by alibaba staff
4.R410A
Parameter List
Product descriptions:
1.Wide selection with the inverter series
Our wide-ranged lineup meets customer needs when it comes to functions and indoor unit types.
2.Enhanced comfort with Daikin inverter
Comfortable air conditioning is achieved through variable output control made possible by the inverter, which continually maintains the set temperature while detecting load, which varies with time of day and number of room occupants.
3.Energy savings with high-efficiency inverter
The outdoor unit is equipped with a reluctance DC scroll compressor that utilizes the latest technology. It brings out the full energy-saving potential of the inverter, which controls power used in accordance with load variation.
4.Reluctance DC Scroll Compressor
Overheating losses are reduced by pressurising the area around the motor, energy saving performance in conjunction with other features.
High thrust mechanism
By introducing high pressure oil, the reactive force from the fixed scroll is added to the internal force, thereby reducing thrust losses. This results in improved efficiency and suppressed sound levels.
5.Smooth Air Inlet Bell Mouth and Aero Spiral Fan
These two features work to significantly reduce noise. Guides are added to the bell mouth intake to reduce turbulence in the airflow generated by fan suction. The Aero Spiral Fan features fan blades with the bent blade edges, further reducing turbulence.
6.DC fan motor
| model | FXDSP63ABP |
| power source | 220V/50Hz |
| refrigeration | R410A |
| motor | DC |
| demension | 200*1100*450(mm) |
| net weight | 23 kg |
| gross weight | 32 kg |
| MCA | 16 A |
| MFA | 0.53 A |
| operation sound | 19.0/17.0/15.0/13.0/11.5 dB(A) |
| wireless remote controller | BRC4L611 |
1)Daikin factory(in Shanghai):
2)Daikin R&D department:
5)we have won many projects:
