Vertical Form Fill Seal Machine

Vertical Form Fill Seal Machine thumbnail-1
Vertical Form Fill Seal Machine photo-1
US$ 3,000 - 6,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New, New
Application:
Chemical, Food, Medical
Packaging Type:
Pouch
Contact Supplier Request Quote Chat Now
E C Packtech Machines Private Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Mumbai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Application Chemical, Food, Medical
Packaging Type Pouch
Packaging Material Plastic, Plastic
Automatic Grade Other, Automatic, Automatic
Driven Type Mechanical
Voltage 220V
Power 3KW
Place of Origin Delhi, India
Brand Name Ecppl, ECPPL
Model Number EC-AFFS, EC-AFFS
Weight 380Kg
Dimension(L*W*H) 750*560*1750
Certification ISO9001:2008
After-sales Service Provided Engineers available to service machinery overseas



Applications:

These machine can be used to pack dry and liquid products such as:



DRY:        Powder, granules, Teadust, Grounded Coffee, Tablets, Candy, Pan Masala, Tobacco, Curry powder, Beans, Salt &

                 Pepper, Cereals, Spices, Detergent Powder, Peanuts, Sugar, Soft drink concentrates, ORS (Rehydration) & other

                 medical powders, Telcum powder, Milk Powder, Henna and many more.



LIQUID:    Shampoos, Hair oils, Liquid detergent, Liquid Hair dye, Lubrication oils, Syrup, Ketchup, Liquid soap and many more.

PASTE:    Shaving Cream, Beauty cream, Ointment, Toothpaste and many more.





Model                         EC3S                                  EC4S                                        ECCS                                EC 2 in 1

Sealing Type             3-Side Sealing                 3-side & 4Side sealing       Centre Seal               3side & 4side sealing Pouch Sizes                                       Width : 20 to 170              Width : 20 to 150                   Width : 20 to 150                Width : 20 to 150

                                    Length : 45 to 240            Length : 45 to 240                Length : 45 to 240             Length : 45 to 240



Filing Range              DRY (gms)                      DRY (gms)         LIQUID (gms)   DRY (gms)                 DRY & LIQUID

                                     a)      0.5 to 10                 a) 0.5 to 10         a) 1 TO 10            a) 0.5 TO 10          a) 0.5 TO 30gms/1 to 25ml.

                                     b)      10 to 30                  b) 10 to 30          b) 10 to 50           b) 10 to 30              b) 30 to 50gms / 25 to 50ml.

                                     c)       30 to 50                  c) 30 to 50          c) 50 to 100         c) 30 to 50             c) 50 to 100gms / 50 to 100ml

                                     d)      50 to 100                d) 50 to 100       d) 100 to 200      d) 50 to 100

                                     e)      100 to 200              e) 100 to 200     e) 100 to 200



Operational Speed

(PPM)                           30 to 100                    DRY        30 to 100                                                                   DRY        30 to 100

                                                                          Liquid    30 to 70                                 30 to 100                      Liquid    30 to 70



Packing Material                          All type of heat sealable laminates and special heat sealable film.



Power   a) MOTOR           ¼ OR ½ H.P 220 VI Single Phase 50 – 60Hz.

                b) HEATER           150w X 2 Nos.                                                                150w X 2 Nos.

                     LOAD               300X X 2 Nos.                     300w X 4 Nos.                 300w X 2 Nos.



Reel Dimensions:                         Outdia max 350mm         core inner dia: 70/76mm

Machine Dimensions                750m X 560mm X 1750mm (LXDXH)

Shipping Dimensions             100mm X 910mm X 1550mm

Net Weight:                                       380Kg. (Approx)

Gross Weight:                                 450kg. (Approx)





OPETIONAL ATTACHMNTS:

1.       Date and Batch No. Coding device-print embossed coding

2.       Batch cutting device.

3.       Inert gas flushing system for extended product shelf life.

4.       Take off conveyors.

5.       Adjustable disc arrangement system.

6.       Telescopic disk system.

7.       Special glass enclosure to avoid product contamination and dusting.

8.       Augur filling system for non free-flowing powders.

9.       Hopper level sensor device

10.   Rat tail cutting device.
