Help Center2d Barcode Tablet
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Screen Size:
Other, 7", 7" 16:9
Processor Manufacture:
AMLogic
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2016 10.1 Inch Quad Core RJ45 NFC Webcam WIFI Dual Cameras 5500mAh TabletNegotiableMOQ: 1 Piece -
10.1 Inch Android Tablet With NFC Function, RJ45, 1GB+8GB, 5500mAh, IPS ScreenNegotiableMOQ: 1 Piece
-
VR BOX 3D MOVIE GAMES Virtual Reality 3D Glasses for Smart PhoneNegotiableMOQ: 1
-
3d Movies Games Self-developed VR Headmounted Display Customization Virtual RealityNegotiableMOQ: 1
-
2016 5.0 Inch HD IPS 1280X720 on Cell Android 6.0 5.0MP Front+8.0 MP AF Rear 2.5D Arc Edge Tech Smart PhoneNegotiableMOQ: 1 Unit
Products Status
Stock
Screen Size
Other, 7", 7" 16:9
Processor Manufacture
AMLogic
Processor Type
Other, Amlogic Cortex-A9 AML8726-M3
Processor Main Frequency
1.0GHz
Hard Drive Capacity
8GB
Memory Capacity
1GB
Touch Screen Type
Capacitive Screen
Display resolution
1024x600
Operating System
Android 4.0
Weight
725g
Place of Origin
China
Brand Name
OEM
Model Number
SZ-BC-001
Battery Life
4-8h
Specifications
1.1024*600 HD IPS,1GB DDR32.with NFC,barcode reader
3.with wifi,GPS,3G,BT
4.Amlogic Cortex-A9 AML8726-M3
5.reasonable price
| System Physical Standard Configuration: | ||||||
| Type | Details | Descriptions | ||||
| Product Form | Product Form | Straight Plate | ||||
| Dimensions | 198mm*117mm*12.8mm | |||||
| LCD | Screen Size | 7" 16:9 | ||||
| Screen Resolution | 1024*600 HD IPS | |||||
| TP | Touch Module | Capacitive | ||||
| Battery | Type | Lithium-ion polymer battery | ||||
| Capacity | 3.7V/4100mAH | |||||
| Endurance | 4-8 Hours | |||||
| System hardware configuration: | ||||||
| Type | Details | Descriptions | ||||
| CPU | Type | Amlogic Cortex-A9 AML8726-M3 | ||||
| Speed | 1.0GHz | |||||
| GPU | Type | Mali 400 | ||||
| Speed | 250MHz | |||||
| Multi-media (Hardware decoding) |
Phote Viewer | BMP, JPG, GIF, PNG | ||||
| Video Format | MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) | |||||
| Audio Format | MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license) | |||||
| RAM | DDR3 | 1GB DDR3 | ||||
| ROM Flash | Nand Flash | 4GB (8GB/16GB/32GB optional) | ||||
| Camera | Front Facing | 0.3MP/(2MP optional) | ||||
| Rear Facing | 5MP /(2MP optional) | |||||
| Speaker | Size | Built-in 8Ω/1.5W speaker x 2 | ||||
| G-sensor | Built-in | 3 axis gravity acceleration sensor | ||||
| GPS | Built-in | No suppport | ||||
| Network Connections: | ||||||
| Type | Details | Descriptions | ||||
| WIFI | WIFI module | WIFI 802.11b/g/n (BT4.0 optional) | ||||
| 3G | Built-in | WCDMA/EVDO/TD-SCDMA(optional),Support voice calls | ||||
| Ethernet Network | MiNi USB switch to Ethernet Network | Supportive | ||||
| Interface Configuration: | ||||||
| Type | Details | Descriptions | ||||
| Memory card socket | External memory | Support SDHC/SDXC | ||||
| USB interface | Data transfer supportive | USB OTG | ||||
| 3G interface | SIM interface | Optional | ||||
| Headphone jack | Music output | 3.5mm standard headphone jack | ||||
| DC connector | Power | 2.5MM power connector | ||||
| HDMI interface | Video output | HDMI 1.4a | ||||
| Keyboard | Input device | Wired / Wireless Supportive | ||||
| Mouse | Input device | Wired / Wireless Supportive | ||||
| Software Configuration: | ||||||
| Type | Details | Descriptions | ||||
| Operating System | Operating system version | Andriod 4.0.3 | ||||
| Language | Multi-language supportive | |||||
| FLASH | FLASH 10.3; Hardware decoding supportive | |||||
| HTML5 | Supportive | |||||
| Application Module | ||||||
| Type | Details | Descriptions | ||||
| one-dimension barcode reader | Interface | TTL232 | ||||
| Reading mode | CCD | |||||
| Resolution | 2500 | |||||
| Decoding speed | max to 300 times/sec | |||||
| Symbologies | Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ISBN/ISSN, Code 93, UCC/EAN-128, GS1 Databar | |||||
| Optical source | LED(622 nm - 628 nm) | |||||
| Optical source intensity | 265 LUX (130 mm ) | |||||
| Type | Details | Descriptions | ||||
| NFC | Chipset/Module | NXP,128K/C2 ROM44kB EEROM | ||||
| RF Frequency | 13.56MHz | |||||
| Support Configuration Mode | Card reader mode,P2Pmode | |||||
| Support Interface | UART,SPI,IIC | |||||
| Module Voltage Range | 2.3V-5.5V | |||||
| Modulation Mode | ASK | |||||
| Module Power Consumption | 30mA(Max) | |||||
| Baud Rate | 9.6 to 460.8 kbps (UART) | |||||
| Work range | <10cm | |||||
| Main Function | Through a serial port realize NFC and MID data exchange, and provide relevant JAVA layer API interfaces |
|||||
| Low power consumption control | ||||||
| Can be read with a ISO14443A/B, ISO15693,Mifare, Felia agreement card | ||||||
| The point-to-point data transmission (P2P mode) | ||||||
| NFC Antenna | The built-in antenna, antenna type: magnetic FPC | |||||
