Model: Inverter DC TIG Welding Machine/ Welder (TIG160S)
Functions and features
* HF arc starting, easy for operation
* Easy for arc striking, stable current, the first choice for thin plate welding
* Little spatter, nice welding surface
* Led digital show functions
Technical Parameters
|
ITEM MODEL |
TIG 160S |
TIG 200S |
TIG 250S |
TIG 300S |
Input power voltage /Frequency (V/HZ) |
Single Phase 220±15% 50/60 |
Single Phase 220±15% 50/60 |
Three Phase 380±10% 50/60 |
Three Phase 380±10% 50/60 |
Rate input power capacity (KVA) |
3.4 |
4.5 |
6.4 |
8.4 |
Output current range (A) |
10-160 |
10-200 |
10-250 |
10-300 |
Rate output voltage (V) |
16.4 |
18 |
20 |
22 |
No-load voltage (V) |
42 |
42 |
56 |
48 |
Duty cycle (%) (25°C) |
60 |
50 |
60 |
50 |
Power factor (COSφ) |
0.93 |
0.93 |
0.93 |
0.93 |
Efficiency (%) |
85 |
85 |
85 |
85 |
Weight (KG) |
8 |
9 |
61 |
18 |
Overall dimension (mm) |
371*153*299 |
371*153*299 |
480*203*368 |
480*203*368 |
Insulation class |
F |
F |
F |
F |
Protection class |
IP23 |
IP23 |
IP23 |
IP23 |
Post-flow time (S) |
5 |
5 |
5 |
5 |
Suitable welding thickness |
0.3-5 |
1.6-6 |
1.6-8 |
0.5-12 |
D. Supply
1. OEM and ODMsevice offered, Machine Color
2. One Year Warranty.
3. Technical Support.
4. CE and CCC certificate
E. Market
South America
Europe
Southeast Asia
Oceania
Mid East
Eastern Asia
F. Strict Quality Control:
Our products are strictly tested 100% before delivery, and approved by CE. And our products are able to meet or exceed some of the industry's most rigid standards. We can ensure you will be satisfied with both performance and durability
G. After-sale Service:
If you have any problem about using the machine, feel free to contact us!
H. Production Line:
