Specifications
Inverter DC TIG Welding Machine/ Welder(TIG160S1. HF arc starting, easy for operation
2. Little spatter, nice welding surface
Model: Inverter DC TIG Welding Machine/ Welder (TIG160S)
Functions and features
* HF arc starting, easy for operation
* Easy for arc striking, stable current, the first choice for thin plate welding
* Little spatter, nice welding surface
* Led digital show functions
Technical Parameters
|
ITEM MODEL |
TIG 160S |
TIG 200S |
TIG 250S |
TIG 300S |
Input power voltage /Frequency (V/HZ) |
Single Phase 220±15% 50/60 |
Single Phase 220±15% 50/60 |
Three Phase 380±10% 50/60 |
Three Phase 380±10% 50/60 |
Rate input power capacity (KVA) |
3.4 |
4.5 |
6.4 |
8.4 |
Output current range (A) |
10-160 |
10-200 |
10-250 |
10-300 |
Rate output voltage (V) |
16.4 |
18 |
20 |
22 |
No-load voltage (V) |
42 |
42 |
56 |
48 |
Duty cycle (%) (25°C) |
60 |
50 |
60 |
50 |
Power factor (COSφ) |
0.93 |
0.93 |
0.93 |
0.93 |
Efficiency (%) |
85 |
85 |
85 |
85 |
Weight (KG) |
8 |
9 |
61 |
18 |
Overall dimension (mm) |
371*153*299 |
371*153*299 |
480*203*368 |
480*203*368 |
Insulation class |
F |
F |
F |
F |
Protection class |
IP23 |
IP23 |
IP23 |
IP23 |
Post-flow time (S) |
5 |
5 |
5 |
5 |
Suitable welding thickness |
0.3-5 |
1.6-6 |
1.6-8 |
0.5-12 |
D. Supply
1 . Supply
1. OEM and ODM sevice offered.
2. One Year Warranty.
3. Technical Support.
4. CE,CCC and ISO9001:2000.
E. Strict Quality Control:
1.Our products are strictly tested 100% before delivery, CCC,CE and ISO9001:2000 got approved. 2.our products are able to meet or exceed some of the industry's most rigid standards. 3.We can ensure that you will be satisfied with both performance and durability.
F. After-sale Service:
1. 1.5% Spare Parts is available for Repairing and Maintaining duirng machines' selling.
2. Our Technician or engineer would be appointed to asist you settle down the problem you can solve.
3.The professional Vedio can be available for training and repairing.
H. Production Line:
