Middle-duty Mounted Disc Harrow for Sale
US$ 1000.00 - 1000.00
MOQ: 200 Sets
Key Specifications
Get Latest Price
Type:
Other, OEM
Use:
Tractors
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Agricultural Machinery-harrowUS$ 1000.00 - 1000.00MOQ: 200 Sets -
Agricultural Machinery-disc HarrowUS$ 1000.00 - 1000.00MOQ: 200 Sets
-
Disc Harrow /Agricultural Machine Disc HarrowUS$ 1000.00 - 1000.00MOQ: 200 Sets
-
20 Discs Hydraulic Heavy Duty Disc HarrowUS$ 1000.00 - 1000.00MOQ: 200 Sets
-
18 Blades Agricultural Machinery Heavy Duty Disc HarrowUS$ 1000.00 - 1000.00MOQ: 200 Sets
Type
Other, OEM
Use
Tractors
Place of Origin
Shandong, China
Brand Name
SR
Model Number
OEM
Products Description
This series are used for crushing clods after tillage, preparing soil before seeding , loosening the soil , combining the soil and fertilizer , and cleaning away stubble of plants in light soil field. With reasonable structure, strong ability to rake , durable , easy to use and maintain , etc.
Products Description
| type | 1BQX-1.1 | 1BQX-1.3 | 1BQX-1.5 | 1BQX-1.7 | 1BQX-2.0 | 1BQX-2.2 | 1BQX-2.3 | |||
| Working width(mm) | 1100 | 1300 | 1500 | 1700 | 2000 | 2200 | 2300 | |||
| Working depth (mm) | 100-140 | |||||||||
| No. of disc (pc) | 12 | 14 | 16 | 18 | 20 | 22 | 24 | |||
| Dia. Of disc (mm) | 460 | |||||||||
| Weight(kg) | 200 | 220 | 250 | 270 | 380 | 400 | 420 | |||
| Linkage | Three point mounted | |||||||||
| Matched power (hp) | 12--18 | 15-18 | 20-25 | 25-30 | 35-40 | 40-45 | 55 | |||
IBQ Serise:
| type | 1BQ-3.4 | 1BQ-5.0 | ||||
| Working width(mm) | 3400 | 5000 | ||||
| Working depth (mm) | 100-140 | |||||
| No. of disc (pc) | 42 | 60 | ||||
| Dia. Of disc (mm) | 460 | 460 | ||||
| Weight(kg) | 1150 | 1550 | ||||
| Linkage | trailed | |||||
| Matched power (hp) | 80-100 | 100 | ||||
| Opposed Light-duty Disc Harrow | |||||||||||||
| type | 1BQDX-1.25 | 1BQDX-1.6 | 1BQDX-2.0 | 1BQDX-2.3 | 1BQDX-2.65 | 1BQDX-3.0 | |||||||
| Ex-factory price | |||||||||||||
| Working width(mm) | 1250 | 1600 | 2000 | 2300 | 2650 | 3000 | |||||||
| Working depth (mm) | 50-150 | ||||||||||||
| No. of disc (pc) | 16 | 20 | 24 | 28 | 32 | 36 | |||||||
| Dia. Of disc (mm) | 460 | ||||||||||||
| Weight(kg) | 330 | 390 | 460 | 560 | 600 | 650 | |||||||
| Linkage | Three point mounted | ||||||||||||
| Matched power (hp) | 35-40 | 40-45 | 50-60 | 60-75 | 75-85 | 85-100 | |||||||
| Mounted Medium Disc Harrow | |||||||||||||
| Type | 1BJX-1.1 | 1BJX-1.3 | 1BJX-1.5 | 1BJX-1.7 | 1BJX-2.0 | 1BJX-2.2 | 1BJX-2.4 | 1BJX-2.5 | 1BJX-2.8 | 1BJX-3.0 | 1BJX-3.4 | ||
| Ex-factory price | |||||||||||||
| Working width(mm) | 1100 | 1300 | 1500 | 1700 | 2000 | 2200 | 2400 | 2500 | 2800 | 3000 | 3400 | ||
| Working depth (mm) | 140 | 140 | 140 | ||||||||||
| No. of disc (pc) | 10 | 12 | 14 | 16 | 18 | 20 | 22 | 24 | 26 | 28 | 32 | ||
| Dia. Of disc (mm) | 560 | 560 | |||||||||||
| Weight(kg) | 320 | 340 | 360 | 420 | 440 | 463 | 604 | 660 | 700 | 1300 | 1400 | ||
| Linkage | Type II Three point mounted | trailed | |||||||||||
| Matched power (hp) | 25-30 | 30-40 | 40 | 45 | 50-55 | 55-60 | 65-70 | 75 | 80 | 80 | 100 | ||
| 1BJ Double Folding Wings in Hydraulic Pressure Offset Middle-duty Disc Harrow | ||||||||
| type | 1BJ-4.4 | 1BJ-5.3 | 1BJ-6.0 | |||||
| Ex-factory price | ||||||||
| Working width(mm) | 4400 | 5300 | 6000 | |||||
| Working depth (mm) | 140 | |||||||
| No. of disc (pc) | 40 | 48 | 56 | |||||
| Dia. Of disc (mm) | 560 | |||||||
| Weight(kg) | 1750 | 2200 | 2520 | |||||
| Linkage | trailed | |||||||
| productivity(Ha/hr.) | 2.7 | 3.3 | 3.5 | |||||
| Matched power (hp) | 75-100 | 100-120 | 100-120 | |||||
| Semi-mounted Offset Heavy-duty Disc Harrow | ||||||||||
| model | 1BZ(BX)-1.8 | 1BZ(BX)-2.0 | 1BZ(BX)-2.2 | 1BZ(BX)-2.5 | 1BZ(BX)-3.0 | |||||
| Ex-factory price | ||||||||||
| Working width(mm) | 1800 | 2000 | 2200 | 2500 | 3000 | |||||
| Working depth(mm) | 200 | |||||||||
| No. of disc (pc) | 16 | 18 | 20 | 24 | 28 | |||||
| Dia. Of disc (mm) | 660 | 660 | 660 | 660 | 660 | |||||
| Weight (kg) | 800 | 850 | 1050 | 1200 | 1350 | |||||
| Linkage | Semi—mounted | |||||||||
| Matched power (hp) | 70-80 | 80-100 | 80-100 | 80-100 | 100-120 | |||||
| Hydraulic Offset Heavy-duty Disc Harrow | |||||||||||||
| Model | 1BZ-2.2 | 1BZ-2.5 | 1BZ-3.0 | 1BZ-3.4 | 1BZ-4.0 | 1BZ-5.3 | |||||||
| Ex-factory price | |||||||||||||
| Diameter of disc | 660 mmX 5 | ||||||||||||
| Weight | 1250 | 1350 | 1430 | 1550 | 1650 | 1780 | |||||||
| Working width (m) | 2.2 | 2.5 | 3 | 3.4 | 4 | 5.3 | |||||||
| Working depth (cm) | 180-200 | 180-200 | 180-200 | 180-200 | 180-200 | 180-200 | |||||||
| Ground clearance (cm) | >160 | >160 | >160 | >160 | >160 | >160 | |||||||
| Maximum working angle | 23 | 23 | 23 | 23 | 23 | 23 | |||||||
| Nos of disc blade | 20 | 24 | 28 | 32 | 36 | 48 | |||||||
| Matched power (hp) | 80 | 80 | 100 | 120 | 120 | 140 | |||||||
