Rail in/ out Welding Steel Ladder Type Cable Tray

Specifications

1.low cost
2.easy for line check and cleaning
3.fast heat dispersion
4.flexible and fast installation.

Cable tray

Both side rail and rung are special-shape aluminium profiles. Reviting or welding formation is used between side rail and rung of cable tray, and surface treatment is hot dipped galvanization. There are several characteristics including high loading capacity, fast heat dispersion.



Material

A6063



Width

750mm - 150mm



Height

100mm/ 150mm/ 200mm



Length

2000mm-6000mm



Thickness

1.5mm/ 2.0mm/ 2.5mm /3.0mm



Surface finished and executive standard

 Anodic oxidation on the surface and the thickness of oxide film is AA15/AA10



Loading capacity

Max. loading capacity NEMA 20A, L 6000m,   loading capacity 75kg/m



Applicable site

 Heavey corresive environment and outdoor power cable



  Factory

Warehouse
