XAX4748 47U lock glass computer pc enclosure chassis case shell casing Rack mount Rackmount Server Cabinet For more information contact
armstrongsu.xaxmetal∂
Advantage
1). White transparent tempered glass front door, black textured screen printing glass on both sides
2). 71% Ventilated Rate of the High-Density Vented Door, 2 round ventilation holes on the top and bottom;
3). Powder coating RAL7035;
4). 4 wheels and hanging ring available
5). Heavy Duty Casters and Leveling Feet, the maximum loading of 800KG (with feet);
6). Flexible and multiple channel alignment on the top and bottom cover, the bottom line hole size can be adjustable
7). Optional mounting base, to fix the cabinet, bottom line, bottom ventilation, rat proof
8). 4 Removable side panels and the rear doors
9). Four post, depth-adjustable rack system with 19" mounts and square holes
10). Perforated roof with cable entry access in the rear
11). Perforated front and rear locking doors (easily removable)
12). Complete optional accessories available
13). Edit by Armstrong Su
Main future
1). Capacity: 24u
2). Dimensions (W x D x H): Check the table below
3). Material: SPCC cold rolled steel
4). Thickness: Mounting profile 0.08" (2.0mm), mounting angle 0.06" (1.5mm), others 0.05" (1.2mm)
5). Surface Finish: Degreasing, pickling, phosphoric, powder coated
6). Degree of Protection:IP20
7). Loading Capacity: 1670lbs
8). Main Parts: Top cover 1 piece, mounting profile 4 pieces, mounting angle 6 pieces, spring lock 2 pieces, key 4 pieces, vented front door 1 piece, heavy duty caster 4 pieces, frame 2 pieces, side panel 2 pieces, bottom panel 1 piece, M6 B-head screw 40 pieces, M6 square nut 40 pieces, Allen wrench 1 piece, M12 adjustable feet 4 pieces
| W*D*H (mm) | W*D*H (inch) | Capacity (U) |
| 600*600*988 | 23.62*23.62*38.9 Inches | 18U |
| 600*600*988 | 23.62*23.62*38.9 Inches | |
| 600*1000*988 | 23.62*39.37*38.9 Inches | |
| 600*600*1166 | 23.62*23.62*45.91 Inches | 22U |
| 600*800*1166 | 23.62*31.5*45.91 Inches | |
| 600*1000*1166 | 23.62*39.37*45.91 Inches | |
| 600*600*1388 | 23.62*23.62*54.65 Inches | 27U |
| 600*800*1388 | 23.62*31.5*54.65 Inches | |
| 600*1000*1388 | 23.62*39.37*54.65 Inches | |
| 600*600*1610 | 23.62*23.62*63.39 Inches | 32U |
| 600*800*1610 | 23.62*31.5*63.39 Inches | |
| 600*900*1610 | 23.62*35.43*63.39 Inches | |
| 600*1000*1610 | 23.62*39.37*63.39 Inches | |
| 600*600*1833 | 23.62*23.62*72.17 Inches | 37U |
| 600*800*1833 | 23.62*31.5*72.17 Inches | |
| 600*900*1833 | 23.62*35.43*72.17 Inches | |
| 600*1000*1833 | 23.62*39.37*72.17 Inches | |
| 600*600*2055 | 23.62*23.62*80.91 Inches | 42U |
| 600*800*2055 | 23.62*31.5*80.91 Inches | |
| 600*900*2055 | 23.62*35.43*80.91 Inches | |
| 600*1000*2055 | 23.62*39.37*80.91 Inches | |
| 600*1200*2055 | 23.62*47.24*80.91 Inches | |
| 600*600*2277 | 23.62*23.62*89.65 Inches | 47U |
| 600*800*2277 | 23.62*31.5*89.65 Inches | |
| 600*900*2277 | 23.62*35.43*89.65 Inches | |
| 600*1000*2277 | 23.62*39.37*89.65 Inches | |
| 600*1200*2277 | 23.62*47.24*89.65 Inches | |
| 800*600*2055 | 31.5*23.62*80.91 Inches | 42U |
| 800*800*2055 | 31.5*31.5*80.91 Inches | |
| 800*900*2055 | 31.5*35.43*80.91 Inches | |
| 800*1000*2055 | 31.5*39.37*80.91 Inches | |
| 800*1200*2055 | 31.5*47.24*80.91 Inches | |
| 800*600*2277 | 31.5*23.62*89.65 Inches | 47U |
| 800*800*2277 | 31.5*31.5*89.65 Inches | |
| 800*900*2277 | 31.5*35.43*89.65 Inches | |
| 800*1000*2277 | 31.5*39.37*89.65 Inches |
1.Each cabinet with PV film
2.foam protect each angels
3.Carton outside
4.Straps
5.fumigation-free pallets and wood case if need
For more information contact
armstrongsu.xaxmetal∂
For more information contact
armstrongsu.xaxmetal∂
1.75 inch, 19inch, 1U, 2U, 3U, 4.45cm, 42U Mainframe Server Storage Rack mount Cabinet Enclosure, 482mm, 600mm, 800mm, ANSI/EIA RS-310-D,IEC297-2,DIN41491; PART1,DIN41494; PART7
