Specifications
1)HHDPE Pond liner/DPE geomembrane2)thickness:0.3mm~3.0mm
3)width:2m~8m
4)China standard or GM13 ASTM standard
Geomembrane is a kind of waterproof material with basic raw material of high molecular polymer. It is mainly divided into LDPE geomembrane, , HDPE geomembrane, and all kinds of composite geomembrane.
- Complete variety of specifications of width and thickness. Thickness: 0.3-2.5mm/Width: 2-8m .
- Excellent environmental stress resistant cracking performance.
- Excellent performance of chemical erosion resistance.
- Big scope of application temperature and long service life .
- Applied in landfill waste site, sewage and filth treatment site, tailings depot and underground construction project
Properties of Geomembrane
|
Spec Properties |
GM0.5 |
GM0.75 |
GM1.0 |
GM1.25 |
GM1.5 |
GM2.0 |
GM2.5 |
Thickness |
0.50mm |
0.75mm |
1.00mm |
1.25mm |
1.50mm |
2.00mm |
2.50mm |
Density ( ≥) |
0.940g/cc |
0.940g/cc |
0.940g/cc |
0.940g/cc |
0.940g/cc |
0.940g/cc |
0.940g/cc |
|
Tensile Properties ( ≥) • yield strength • break strength • yield elongation • break elongation |
7 kN/m 10kN/m — 600% |
10 kN/m 15kN/m — 600% |
13 kN/m 20 kN/m 11% 600% |
16 kN/m 25 kN/m 11% 600% |
20 kN/m 30 kN/m 11% 600% |
26 kN/m 40 kN/m 11% 600% |
33kN/m 50kN/m 11% 600% |
Tear Resistance ( ≥) |
56 N |
84 N |
115 N |
140 N |
170 N |
225 N |
280 N |
Puncture Resistance ( ≥) |
120 N |
180 N |
240 N |
300 N |
360 N |
480 N |
600 N |
Carbon Black Content ( ≥) |
2.0-3.0% |
2.0-3.0% |
2.0-3.0% |
2.0-3.0% |
2.0-3.0% |
2.0-3.0% |
2.0-3.0% |
Carbon Black Dispersion ( ≥) |
Note(1) |
Note(1) |
Note(1) |
Note(1) |
Note(1) |
Note(1) |
Note(1) |
|
Oxidative Induction Time(OIT) Standard OIT ( ≥) |
60 min. |
60 min. |
60 min. |
60 min. |
60 min. |
60 min. |
60 min. |
Note(1): Carbon black dispersion (only near spherical agglomerates) for 10 different views:
9 in Categories 1 or 2 and 1 in Category 3
