Elevator Guide Rails – Frequently Asked Questions
How to name guide rails?
The departure point of naming guide rails varies from country to country. Some name the guide rail according to the width of its aspect of guiding, such as T9, T16. While others name based on its weight, like 8LB, 12LB . However, we mostly name guide rail according to its width of bottom, for example: T70, T50.
What difference is there between cold-drawn and planed guide rails?
The process for cold-drawn involves stretching the material thus modifying its structure. Planing involves machining the guide rail by stripping the edgings.
Are the speed limits for the different qualities precise?
No, the calculations for comfort are carried out using a mathematical model validated with practical tests, hence the speed limits set are approximate.
Why are the guide rails 5 meters long?
The guide rails are 5 meters long because it is the appropriate manufacturing length and allows the parameters for straightening to be checked properly.
Do the guide rails have any surface treatment?
No, the guide rails do not have surface treatments. On cold-drawn guide rails the cold-drawn process modifies the mechanical features of the material.
1.The types of guide rails basic dimensions: are as follow
T45/A: 45*45*5mm
T50/A: 50*50*5mm
T70-1/B,T70/A: 70mm*65mm*9mm
T75/B orT75-3/B: 75mm*62mm*10mm
T78/B: 78mm*56mm*10mm
T82/B: 82.5mm*68.25mm*9mm
T82-3/B:82mm*62mm*15.88mm
T89/B or T89-1/B: 89mm*62mm*16mm
T90/B: 90mm*75mm*16mm
T114/B:114*89*16mm
T127-1/B: 127*89*16mm
T127-2/B: 127*89*16mm
TK5A
TK5
TK3A
food elevator
2. Material: all types of Elevator steel guide rails material is Q235
Item Grade |
Chemical Composition |
||||
C |
Mn |
Si |
S |
P |
|
Q235 |
0.14-0.22 |
0.35-0.65 |
0.12-0.30 |
≤0.05 |
≤0.045 |
Mechanical property |
|
||||
Yield Strength N/mm2 |
Tensile Strength N/mm2 |
Elongation |
|
||
≥235 |
400-450 |
≥24 |
|
||
3. remarks
All our products are produced according to ISO7465 international standard. If you have your own standard, we can also produce according to your specific dimensions. Dimensions displayed here is only a brief version. If you want details, please contact me.
TAICANG XINXING MACHINERY FACTORY is a factory of elevator guide rails that has been established since2001. Our factory mainly provides machinery processing services to a specialized manufacturer of a series of guide rails for elevators. In 2008, we started foreign trade business. Our factory has passed ISO 9001 Certification. And our guide rails has passed type test in our industry. we are located in Taicang SUZHOU.
