Technical Data ALUMINIUM & PVC COMBINED FLEXIBLE AIR DUCTS
lMax temperature: 140 °C
l Diameter:3" ~48" ( 076mm ~ 1200mm).
l Optional colour: black, white, grey.
l Standard length:10 metre compressed to 0.4-0.6metre.
l Material;combination of an aluminium/polyester laminated
Advantages ALUMINIUM & PVC COMBINED FLEXIBLE AIR DUCTS
- Combination of mechanical strength and high temperature.
- Suitable for the Heating and Ventilation Market and industrial purposes, such as for the exhaust of welding
- Because of an interior of aluminium the temperature range is up to 140°C and the outside layer gives a mechanical strong product.
-
ALUMINIUM & PVC COMBINED FLEXIBLE AIR DUCTS specification
- flexible ducting with a reinforced PVC polyester riber
- cloth with an encapsulated high tensile steel wire helix.
- Acid and alkali resistance.
- Ideal for use in general purpose exhaust applications including
- bathroom fans , furnace mounted humidifier units, air conditioning
- ventilation system
-
we are manufacter
Our clients choose us for reasons
- we pay attention to the quality as company life, we are in the line of middle & high quality air filter and duct,
- We look into the details and timely delivery guaranteed.
- Pleasant service and respond quickly.
- Reasonable price
- around 2 hours to Shanghai
your will find it's the right choose for doing business with us!
for more white ALUMINIUM & PVC COMBINED FLEXIBLE AIR DUCTS ,pls contact me by e-mail
Specifications
a.PVC aluminum combine duct
b.High temperature resistant
c.Excellent resistance to chemicals
d. Flame-retardant .
TECHNICAL SPECIFICATIONS
Construction Aluminium + PVC
Available Diameters Ø 52 mm - Ø 630 mm
Temperature Range - 30 º C / + 150 º C
Air Velocity 30 m/s ( Max. )
Operating Pressure 3000 Pa ( Max.)
Standard Length 10 m
Fire Resistance Fire Retardant
"1)aluminum foil air ducting for ventilation of fumes chemicals and hot gas
2) High temperature resisitant up to 150 degree
"
Name: Aluminum foil laminated PVC ducting
"1)PVC combined ducting for extraction of fumes chemicals and hot air
2) High temperature resisitant up to 150 degree centigrade"
PVC combined air ducting made of aluminum foil laminated with PVC film
Application:
1)Suction and blower hoses for hot air and gas up to +150 °C
2)Air conditioning and ventilation of fumes,high-temperature gas , chemical gas .
3)Extraction of corrosive gases and fumes
4)Chemical plants
5)Transfer of hot and cold air
6)Air conditioning/ventilation
7) Vehicle construction
Features :
1) High temperature resistant
2) Excellent resistance to chemicals
3) Acid & Alkali Resistance4
4)Highly flexible
5)Small bending radius
Working temperature :
-20 degree up to +150 degree
Materials :
Wall :Aluminum foil laminated PVC film
Spiral : Steel wire
Send Inquiry to This Supplier
