06EA265, 06EA565 Carrier 06E Air Conditioner Compressor, Carlyle 06EA Semi-Hermetic Reciprocating Air Conditioner A/C Compressor
- 1000 Piece / Pieces per Month
- Shanghai
Product Details
Place of Origin: | United States | Brand Name: | Carrier | Model Number: | 06EA265, 06EA565 |
Type: | Refrigeration Compressor | Application: | Refrigeration Parts | Certification: | UL |
Product Description
Carlyle 06D/E semi-hermetic compressors are ideally suited for commercial refrigeration, air conditioning, process cooling, and environmental chambers. They are extremely flexible and may be used with many of the new HFC refrigerants such as R-507, R-404A, R-407C and R-134a, in addition to the conventional refrigerants (R-12, R-22, and R-502). The compressors may be operated at 50 or 60 hertz and are UL, CE, CSA, and ISO 9002 approved. Many of the prominent features of the 06D/E compressors are listed below.
High-flow, automatically reversible oil pump provides positive-displacement oil lubrication.
Crankcase venting system equalizes pressure during startup and assures oil return to sump.
Oversize sump holds extra oil in crankcase to prevent levels dropping below safe lubrication range during flooded starts.
Contoured pistons lower cylinder clearances to increase compressor capacity and efficiency.
High-efficiency valves provide increased refrigerant flow and lower pressure drops.
Electronic oil-pressure switch.
MODEL | HP | CFM @ 1750 RPM | SUCTION TEMPERATURE RANGE (DEGREES F) | CYL NO | BORES (INCHES) | STROKE (INCHES) | OIL CHARGE (PINTS) | NET WEIGHT (LBS) | |||||
R502/R404A/R507 | R12/R134a | R22 | |||||||||||
MIN | MAX | MIN | MAX | MIN | MAX | ||||||||
06DR109 | 2.0 | 8.7 | -40 | 0 | -10 | 55 | -35 | 0 | 2 | 2.00 | 1-3/8 | 3.00 | 160 |
06DM808 | 3.0 | 8.0 | 0 | 50 | – | – | 0 | 55 | 2 | 2.00 | 1-1/4 | 3.00 | 160 |
06DR013 | 3.0 | 13.1 | -40 | 0 | -10 | 55 | -35 | 0 | 4 | 2.00 | 1 | 4.50 | 230 |
06DM313 | 5.0 | 13.1 | 0 | 50 | – | – | 0 | 55 | 4 | 2.00 | 1 | 4.50 | 235 |
06DR316 | 5.0 | 15.9 | -40 | 25 | -10 | 55 | -35 | 25 | 4 | 2.00 | 1-1/4 | 4.50 | 235 |
06DM316 | 5.0 | 15.9 | 0 | 25 | – | – | 0 | 45 | 4 | 2.00 | 1-1/4 | 4.50 | 235 |
06DR718 | 5.0 | 18.3 | -40 | 0 | -10 | 55 | -35 | 0 | 4 | 2.00 | 1-7/16 | 5.50 | 250 |
06DA818 | 6.5 | 18.3 | 0 | 50 | – | – | 0 | 55 | 4 | 2.00 | 1-7/16 | 5.50 | 250 |
06DR820 | 6.5 | 20.0 | -40 | 40 | -10 | 55 | -35 | 45 | 4 | 2.00 | 1-9/16 | 5.50 | 260 |
06DR724 | 6.5 | 23.9 | -40 | 25 | -10 | 55 | -35 | 45 | 6 | 2.00 | 1-1/4 | 8.00 | 310 |
06DR725 | 6.5 | 23.9 | -40 | 25 | -10 | 55 | -35 | 45 | 6 | 2.00 | 1-1/4 | 8.00 | 310 |
06DA825 | 7.5 | 23.9 | 0 | 50 | – | – | 0 | 55 | 6 | 2.00 | 1-1/4 | 8.00 | 315 |
06DA824 | 7.5 | 23.9 | 0 | 50 | – | – | 0 | 55 | 6 | 2.00 | 1-1/4 | 8.00 | 310 |
06DR228 | 7.5 | 28.0 | -40 | 25 | -10 | 55 | -35 | 45 | 6 | 2.00 | 1-15/32 | 8.00 | 315 |
06DA328 | 10.0 | 28.0 | 0 | 50 | – | – | 0 | 55 | 6 | 2.00 | 1-15/32 | 8.00 | 315 |
06DR337 | 10.0 | 37.1 | -40 | 25 | -10 | 55 | -35 | 45 | 6 | 2.00 | 1-15/16 | 8.00 | 325 |
06DM337 | 10.0 | 37.1 | 0 | 25 | – | – | 0 | 45 | 6 | 2.00 | 1-15/16 | 8.00 | 325 |
06DA537 | 15.0 | 37.1 | 0 | 50 | – | – | 0 | 55 | 6 | 2.00 | 1-15/16 | 8.00 | 325 |
06DR541 | 15.0 | 41.0 | -40 | 25 | -10 | 55 | -35 | 25 | 6 | 2.00 | 2.15 | 8.00 | 325 |
06ER450 | 15.0 | 50.3 | -40 | 0 | – | – | -35 | 0 | 4 | 2-11/16 | 2-3/16 | 14.00 | 430 |
06EM450 | 15.0 | 50.3 | 0 | 25 | -10 | 55 | 0 | 45 | 4 | 2-11/16 | 2-3/16 | 14.00 | 430 |
06EA550 | 20.0 | 50.3 | 0 | 50 | – | – | 0 | 50 | 4 | 2-11/16 | 2-3/16 | 14.00 | 430 |
06ER465 | 20.0 | 68.3 | -40 | 0 | – | – | -35 | 0 | 6 | 2-11/16 | 1-63/64 | 19.00 | 480 |
06EA565 | 25.0 | 68.3 | 0 | 50 | -10 | 55 | 0 | 50 | 6 | 2-11/16 | 1-63/64 | 19.00 | 485 |
06ER475 | 20.0 | 75.4 | -40 | 0 | – | – | -35 | 0 | 6 | 2-11/16 | 2-3/16 | 19.00 | 490 |
06EM475 | 25.0 | 75.4 | 0 | 40 | -10 | 55 | 0 | 45 | 6 | 2-11/16 | 2-3/16 | 19.00 | 490 |
06EA575 | 30.0 | 75.4 | 0 | 50 | – | – | 0 | 50 | 6 | 2-11/16 | 2-3/16 | 19.00 | 490 |
06ER399 | 30.0 | 99.0 | -40 | 0 | – | – | -35 | 0 | 6 | 2-11/16 | 2-7/8 | 19.00 | 500 |
06EM499 | 35.0 | 99.0 | 0 | 40 | -10 | 55 | 0 | 45 | 6 | 2-11/16 | 2-7/8 | 19.00 | 505 |
06EA599 | 40.0 | 99.0 | 0 | 50 | – | – | 0 | 50 | 6 | 2-11/16 | 2-7/8 | 19.00 | 520 |
06E REGULAR MODELS
R22 | R404A |
06ER150600 | 06ER4506A0 |
06ER165600 | 06ER4656A0 |
06ER175600 | 06ER4756A0 |
06ER099600 | 06ER3996A0 |
06EM150600 | 06EM4506A0 |
06EA265600 | 06EA5656A0 |
06EM175600 | 06EM4756A0 |
06EM199600 | 06EM4996A0 |
06EA250600 | 06EA5506A0 |
06EA265600 | 06EA5656A0 |
06EF265600 | 06EF5656A0 |
06EA275600 | 06EA5756A0 |
06EF275600 | 06EF5756A0 |
06EA299600 | 06EA5996A0 |
06EF299600 | 06EF5996A0 |
06ER750600 | 06ER7506A0 |
06ER765600 | 06ER7656A0 |
06ER775600 | 06ER7756A0 |
06ER799600 | 06ER7996A0 |
06EM750600 | 06EM7506A0 |
06E2265600 | 06E25656A0 |
06EM775600 | 06EM7756A0 |
06EM799600 | 06EM7996A0 |
06E2250600 | 06E25506A0 |
06E2265600 | 06E25656A0 |
06E6265600 | 06E65656A0 |
06E2275600 | 06E25756A0 |
06E6275600 | 06E65756A0 |
06E2299600 | 06E25996A0 |
06E6299600 | 06E65996A0 |
06E3265600 | 06E35656A0 |
06E7265600 | 06E75656A0 |
06E3275600 | 06E35756A0 |
06E7275600 | 06E75756A0 |
06E3299600 | 06E35996A0 |
06E7299600 | 06E75996A0 |
