RHM-E212 Sauna Lock Sauna Cabinet Lock for spa center hotel

Specifications

1.Card Type: RFIC
2.Power Supply: DC6V, 4 pieces of AA alkaline batteries
3.Lack of voltage indication

Sauna Lock Sauna Cabinet Lock for spa center hotel



100% Brand New!Widely Used For Home, Office, Apartment



Application: Cabinet, Storage Box, Swimming pool , Sauna bathing spot, Golf course, Gymnasium locker,Enterprise, School, Hotel, Supermarket storage cabinet ,etc



Unlock Ways: RFIC



Performance and Specification:
1. Card Type: RFIC

2. User can set locking doors using whether single card or double cards. ID makes use of electromagnetic wave tech. The induction is more sensitive and the distance is less than 3cm.
3. Power Supply: DC6V, 4 pieces of AA alkaline batteries can be used for more than 1 year. Attached power supply head is prepared.
4. The main chip of circuit board is the US. Texas Instrument TI Chip, the power consumption of which is low. Static Current::≤5-10uA, Card Reading Current::≤20mA,Lock Opening Current: about 300mA(last for 0.3s). work settings: temperature::-20°C~+70°C,humidity::≤95% RH;
5. Lack of voltage indication: when the voltage is less than 4.8V, the lock will give a indication and the red LED will light. At the same time, you can still open the lock for more than 50 times;
6. Use: hotels,sauna centers,office cabinet doors
7. Specialties: Using the cards to open the door. The door will open automatically. Handle is not needed. You can use mechanical equipment to open the door for emergencies. Combined gears movement to ensure the safety and the reliability. Watch band type cards are worn for convenience. It prevents from water, humidity, high temperature, tampering and erosion. When the voltage is more than 15000V, it can ensure the information not missing under the strong interference of strong anti-static electricity.
8. System Settings: a front lock body, a core of lock,a door holder module,door open cards.
9. It can be made to Mifare type. Mifare is a new type which is applicable to hotel locks, entrance guard, work attendance check, card reader/writer,realizing One-Card-Pass.





Sauna lock features:







1. With an external power supply (audio type) port



2.Combination of gears motion, safe and reliable operation



3.Watchband cards, portable, waterproof, anti-high temperature, corrosion



4. Single, double card unlocking mode can be set up according to your needs



5.In exceptional circumstances, you can open the door by mechanical device



6.Voltage lower than 4.8V, open the door with a card, the lock will alarm each



7.Door lock can be automatically bounce, by using the card, door locks automatically bounce,



do not need to install the door handle







Sauna lock technical parameters :







Static power consumption	< 8UA
Power consumption	< 150MA
Low-voltage directives	4.8V
Operating temperature	-30°C~80°C
Battery life	more than 12 months.
Anti-static	> 15000V, the information will not be lost
Unlock ways	TM / EM card to open the door, avoid of illegal card
Power type	4 2A1.5v alkaline   batteries (with external power supply)
The strong electrical interference and it can work steadily.
