nanxin PPR PIPE AND FITTINGS Language OptionDetailed Product Description
Certificate: CE; ISO9001
Pressure: PN1.25Mpa; PN1.6Mpa; PN2.0Mpa; PN2.5Mpa
Size: 16-160 mm
15 years experience in PP-R line
Features:
Material: Random Polypropylene
Sizes: 16 to 160mm
Pressure: PN1.25Mpa; PN1.6Mpa; PN2.0Mpa; PN2.5Mpa
Colors: Light grey, white or other colors on request
Connection: Welding
Standard: GB/T18742.2-2002; DIN8077/8078
Certification: CE, ISO9001
Applications: Cold or hot water supply, heating system, wall heating and radiating system
Advantages:
High Temperature Resistance: the maximum sustained working temperature is up to 70 °C,the maximum transient temperature is up to 95°C
Heat Preservation: low thermal conductivity which is only 1/1500 of brass pipe. And 1/250 of steel pipe.
Non-toxic: no heavy metal additives, would not be covered with dirt or contaminated by bacterium.
Corrosion Resistant: resist chemical matters or electron chemical corrosion.
Lower Installation Costs: light weight and ease of installation can reduce installation costs by as much as 50%over metal piping system.
Higher Flow Capacity: smooth interior walls result in lower pressure loss and higher volume than metal pipes.
Long Life: more than 50 years under normal conditions
Recycled and Environment-friendly
PP-R Water Supply Pipe:
|
|
PN1.25 Mpa |
PN1.6Mpa |
PN2.0Mpa |
PN2.5Mpa |
|
Outer Diameter (mm) |
Wall Thickness (mm) |
Wall Thickness (mm) |
Wall Thickness (mm) |
Wall Thickness (mm) |
16 |
|
2 |
2.2 |
2.7 |
20 |
2 |
2.3 |
2.8 |
3.4 |
25 |
2.3 |
2.8 |
3.5 |
4.2 |
32 |
2.9 |
3.6 |
4.4 |
5.4 |
40 |
3.7 |
4.5 |
5.5 |
6.7 |
50 |
4.6 |
5.6 |
6.9 |
8.3 |
63 |
5.8 |
7.1 |
8.6 |
10.5 |
75 |
6.8 |
8.4 |
10.3 |
12.5 |
90 |
8.2 |
10.1 |
12.3 |
15.0 |
110 |
10 |
12.3 |
15.1 |
18.3 |
160 |
14.6 |
17.9 |
21.9 |
26.6 |
