Specifications
Reverse polarity SMA male body ,female socket for LMR195 cable
According to the request of customer, the reverse polarity connectors produced by our company is to distinguish with difference original series products.(for example SMA, TNC, BNC, etc). It can change the link firm, prevent mistakes. And diminish the systematic wastage. It has the same technical characteristic, standard same with the original series of products.
Temperature Range |
-55~+155°C (PE Cable -40~+85°C) |
|
Impedance |
50Ω |
|
Vibration |
98m/S2 (10~2000Hz), 10g |
|
Frequency Range |
DC-12.4GHz(semi-rigid cable DC-18 GHz) |
|
Insertion Loss |
<= 0.15dB/6GHz |
|
Withstanding Voltage |
1000V r.m.s at sea level |
|
Working Voltage |
335Vr.m.s at sea level |
|
Insulation Resistance |
>= 5000 MΩ |
|
Durability |
>= 500(cycles) |
|
Contact resistance: |
CenterContact <= 3mΩ |
|
Outer Contact <= 2.5mΩ | ||
Voltage Standing Wave Ratio: |
Straight |
flex cable <= 1.10+0.02f |
Semi-rigid cable <= 1.07+0.018f | ||
Right angle |
flex cable <= 1.20+0.03f |
|
Semi-rigid cable <= 1.17+0.02f | ||
