Automatic Washing Filling Capping Machine
- 10 Set / Sets per Month
- Shanghai
- T/T
- Cheapest Automatic Bottle Blowing Machine Prices/factory price automatic bottle shrink wrapping machine
- PET bottle making machine/nice plastic bottle making machine price/high quality plastic bottle blowing machine
- Top quality china automatic machines to make plastic bottles/bottle blowing machinery/Pet Bottles Blowing Machine 750ml
- Chinese PET water bottle blowing machine/equipment / automatic bottle Blowing machinery
- Low price Beverage drinking PET bottle blowing machinery/fully automatic pet bottle blowing machine
- high quality bottle blowing machine/automatic shrink wrapping machine/water bottle blowing machine
Product Details
Packaging Type: | Bottles | Packaging Material: | Plastic, Glass | ||
Automatic Grade: | Automatic | Driven Type: | Electric | Voltage: | 220/380V |
Power: | 2-11KW | Place of Origin: | Jiangsu, China | Brand Name: | Hyford |
Model Number: | DGCF Series | Weight: | 2000-12000kg | Certification: | CE, ISO, SGS |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Washing Filling Capping Machine1.Product: carbonated drink
2.Capacity: 3000-30000b/h(500ml)
3.PLC control, touch screen
Automatic Washing Filling Capping Machine (for Carbonated Drink)
Introduction of the Washing Filling Capping Machine:
This machine contains washing, filling and capping with complete automation. It is suitable for filling all kinds of carbonated drinks such as coco cola, soda water etc into polyester bottles and PET bottles. The bottleneck blocking makes the process of changing bottles easily by only adjusting the height of the conveyor chain. The filling process adopts micro-pressure technology, which makes filling process faster and more reliable.
Main Parameters of this DGCF Series Carbonated Drink Washing Filling Capping Machine
Model | Washing Heads | Filling Heads | Capping Heads | Production Capacity (B/h 500ml) | Main Motor Power (KW) |
DGCF18-18-6 | 18 | 18 | 6 | 5000 | 3.5 |
DGCF24-24-8 | 24 | 24 | 8 | 8000 | 3.8 |
DGCF32-32-10 | 32 | 32 | 10 | 12000 | 5.5 |
DGCF40-40-10 | 40 | 40 | 10 | 15000 | 7.5 |
DGCF50-50-12 | 50 | 50 | 12 | 18000 | 12 |
DGCF60-60-15 | 60 | 60 | 15 | 24000 | 13.5 |
DGCF72-72-16 | 72 | 72 | 16 | 28000 | 15 |
Main Features of the Washing Filling Capping Machine:
Air Conveyor connectes with bottle-in starwheels. Bottle neck holding transferred.
Clamp transferring technology varied bottle types.
With little abrasion. Stable Transferring. Easy to change bottles.
With ring type pressure bearing hydraulic cylinder
With high filling speed and exact liquid level.
Excellent Stainless Steel. Electric Components are of world known brand. All achieve national sanitary standard.
The bottle-out starwheel is of screwdown shape. No need to adjust transferring chain's height to different bottles. Easy to operate and maintain.
PLC and transducers and othe main electric parts are of world famous brands, such as OMRON, MITSUBISHI etc.
