spray painting machine for wood door procution line

Product   Description:

Process:

Wooden door in the place for the online, through the chain
conveyor to automatic spray paint machine in the central conveying process,
automatic controller test the size of the door (and on the basis of calculation
of the gun walk path),and painting processing, after the completion of the
automatic conveyer to flow flat line, the short time leveling, wooden door is
automatically sent to flip institutions and automatic flip, turn wood door by
chain conveyor to be a automatic spray paint machines to automatic spray paint
,after the completion of the chain automatically transported by 12 meters long
leveling machine table dry after complete, off the assembly line, the line can
link UV oven or Infrared ray leveling machine.

Features:
1,this production line is composed of two five shaft
automatic spray paint machine, many sets of leveling machine and wood door flip
institutions into.

2,there are positive pressure ventilation system, water clean
system work environment, guarantee the spraying effect.

3,paint flip and drying the flow operation mode, and the
shorter the paint dry period, and enhance the whole line production capacity,
according to the eight hours every project gush door can be 250-350 sets.

4,in the course of transmission ,there are automatic controller
to test the width of wood door ,no need manual changes.

5,to achieve continuous specification optional wood paint,
the whole line can be connected UV machine, increase dry line length.
