Help CenterDistinguished Automatic Painting Equipment for Door
Related Products
-
Outstanding Painting Machine FXF250-M Automatic Spray Paint MachineNegotiableMOQ: 1 Set -
Furniture Spray Painting EquipmentNegotiableMOQ: 1 Set
-
Brilliant FXF250-M Machine for Wooden DoorsNegotiableMOQ: 1 Set
-
CNC SPRAY PAINTING MACHINE 5 AXIS DESKTOPNegotiableMOQ: 1 Set
-
Advanced Paint/painting/coating Machine ManufacturerNegotiableMOQ: 1 Set
Product Introduction:
1. Rotary double-position feeding and automatic turnover mechanism are provided, to complete all door faces spray
With one effort, reducing working procedure and increasing efficiency;
2. Only two operators are sufficient to complete the whole procedure, with output per shift up to 160-240 wood doors;
3. Spray gun movement route is under computer precise control, to ensure uniform spray and paint saving;
4. Simplified clamps are provided, needing no change of current working procedure, being convenient and practical;
5. Operators and spray guns are isolated, to effectively guarantee operators' health;
6. 2 spray guns are provided in general, while 4 spray guns can be installed at the most.
7.Control the system
Through continuous research, our company has developed a new generation control system, in which an new autom atic programming system has been added on basis of the old system(namely point-to-point programming system). For new system, when you input length and width of products into the computer, the paint spraying machine will perform paint spraying according to preset technology. It is also possible to change the size of products without shutting down so as to achieve the effect of rapid production and paint saving.
8.Air Purifying System
The air will through percolation, from the engine room crest of the net sends into spray to paint the space after filtering, spraying surplus oil fog of the paint creation and varnishing the flavor was taken to spray to paint by the mighty current of air building collection the inside passes water fog decontamination empress that several waters fog of the stainless steel water plank empress spray a jet, from row breeze tube fly to eject.
9.Cleaning System
This system is made up of a tank two fans and a pump.
Attached drencher curtain with floor cleaning device, collected the redundant paint mist during the spray-painting process, through water mist purifying by many drencher heads ejected that behind the drencher curtain board, then drained by exhaust fan.
Technique parameter: | |
Maximum processing length |
2.5M |
Maximum processing width |
1.2M |
Maximum processing thickness |
0.15M |
Spry gun running speed |
0~1500MM/S |
Spray gun caliber |
1.1-1.4 |
Servo motor(total) |
4KW |
Air pressure |
0.6mpa |
Paint type |
PE,PC,PU,UC,XU,UV,(Water paint) |
Overall sizes |
4.2 X 2.35 X 2.5M |
Water pump power |
1.5KW |
Inlet fan power |
3KW |
Exhausting fan power |
2.2KW |
How to distinguish between genuine and fake:
My machine have the Patent certificate of the People's Republic of China as below:
