Home > Security & Protection > Surveillance, Control & Protection > CCTV Camera > 960P 1.3MP IP66 Vandal-proof Dot Matrix 2.8-12mm Varifocal Lens CMOS Metal HDCVI Camera
960P 1.3MP IP66 Vandal-proof Dot Matrix 2.8-12mm Varifocal Lens CMOS Metal HDCVI Camera
US$ 15 - 50
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ZBRAVO
Model Number:
Z-C5970N
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen / Hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
1080P IP66 Vandal-proof 2.8-12mm 2MP Varifocal Lens CMOS 2.0MP Metal HDCVI CameraUS$ 15 - 50MOQ: 1 Piece -
CMOS 45meters IR IP66 Water-proof 1080P Vari-focal HDCVI CameraUS$ 15 - 50MOQ: 1 Piece
-
CMOS 45meters IR IP66 Water-proof 1.3MP Vari-focal HDCVI CameraUS$ 15 - 50MOQ: 1 Piece
-
1080P CMOS 45meters IR IP66 Water-proof 2.0MP Vari-focal HDCVI CameraUS$ 15 - 50MOQ: 1 Piece
-
45m IR Distance 2.8-12mm 2MP Varifocal Lens Metal 1080P IP66 Vandal-proof HDCVI CameraUS$ 15 - 50MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
ZBRAVO
Model Number
Z-C5970N
Type
Analog Camera
Style
Bullet Camera
Sensor
CMOS
Technology
Infrared
Special Features
Other, 960P HDCVI Camera
960P 1.3MP IP66 Vandal-proof Dot matrix 2.8-12mm Varifocal Lens CMOS Metal HDCVI Camera
- Model : Z-C5970N
- CCD + DSP : DH9801+ SONY IMX225
- Image Sensor : 1.3Megapixel 960P HDCVI Camera
- Horizontal Resolution : 960P
Effective Pixels (PAL / NTSC) : 1280(H)×960(V)
- Led: 2pcs Dot IR
- IR range : 45m
- 2.8-12mm 3MP varifocal lens
- Color: White/Korean grey
- Weight: 1.5KG
- Dimension : 270x107x148 mm
| Model | Z-C5970D | Z-C5970N | Z-C5970L |
| CCD + DSP | DH9801+3100 | DH9801+SONY225 | DH9801+SONY322 |
| Image Sensor | 1.0 Megapixel CMOS | 1.3 Megapixel CMOS | 2.0 Megapixel CMOS |
| Horizontal Resolution | 720P | 960P | 1080P |
|
Effective Pixels (PAL / NTSC) |
1280(H)×720(V) | 1280(H)×960(V) | 1920(H)×1080(V) |
| TV System | PAL/NTSC | ||
| Compression | H.264 | ||
| Lens | 2.8-12mm 3MP Varifocal Lens | ||
| IR Leds | 2pcs Dot IR Led | ||
| IR Range | 45Meters Night Vision | ||
| Day/Night | Auto(ICR)/B&W/Color | ||
| Scanning System | 2:1Interlace | ||
| Minimum illuminator | 0.001Lux/F1.2 | ||
| S/N Ratio | >=58dB(AGG OFF) | ||
| AES | 1/50-1/100,000sec(PAL),1/60-1/100,000sec(NTSC) | ||
| DNR | 3D-DNR | ||
| WDR | DWDR | WDR | |
| Transmission Distance | Over 500m via 75-3 coaxial cable | ||
| Video Output | 1-channel BNC high definition video output | ||
| AGC | Auto/Manual/Off | ||
| White Balance | ATW/Manual/Auto | ||
| Synchronization System | Internal Synchronization | ||
| Dimension | 270(L)x107(W)x148(H)mm | ||
| Consumption | <5W | ||
| Working Humidity | ≤90% | ||
| Voltage | DC12V (9V ~ 15V) | ||
| Operating Temperature | —20℃~60℃ / 10% ~ 95%RH | ||
