Specifications
Cutting machine:1. High precision and high speed
2. High efficiency and stability
3. Easy operation
4. Perfect result
HSC SERIES HIGH PRECISION & HIGH SPEED ROLLING SHEET CUTTING MACHINE
Features:
1. This cutting machine adopted the advanced technology of Taiwan and England. It's transmitted by AC sevo motor and has the features of high speed and stability.
2. PLC system, man-machine interface operation and dynamic display are adopted.
3. Imported German cutting knife is used to extend the useful life effectively.
4. Reasonable reversing bend structure are adopted to flat sheets which can ensure the evenness of sheets.
5. Stepless adjusting feeding method can ensure the single sheet feeding and overlapping feeding smoothly.
6. Automatic preparing material and automatic counting and inserting labels function can ensure sheets are delivered orderly.
7. It is a cutting machine of high efficiency and high benefit.
Technical specifications:
Model |
HSC1400 |
HSC1700 |
Cutting accuracy(mm/m) |
±0.5 |
±0.5 |
Max cutting speed(pcs/min) |
300 |
300 |
Max speed(m/min) |
300 |
300 |
Cutting length range(mm) |
450~1450 |
450~1450 |
Max roll paper diameter(mm) |
1800(71") |
1800(71") |
Weight(kg) |
12000 |
13000 |
Total power(kw) |
15 |
16 |
Height of paper stack(mm) |
1300 |
1300 |
Sheet weight(g) |
60-550 |
60-550 |
