Help CenterIce Cream Paper Corn Forming Machine
Related Products
-
Automatic Paper Cup Handle Gluing Machine JBZ-NNegotiableMOQ: 1 Unit -
Paper Cup Handle Gluing Machine ZB-12NegotiableMOQ: 1 Unit
-
Semi-auto Paper Meal Box(plate) Forming Machine ZHCJ-IINegotiableMOQ: 1 Unit
-
HIGH SPEED AUTOMATIC PAPER PLATE FORMING MACHINENegotiableMOQ: 1 Unit
-
Paper Barrel Forming Machine JBZ-WNegotiableMOQ: 1 Unit
Specifications
Forming machine1. High efficiency
2. Easy installation
3. High precise
4. Easy operation and maintenance
JXG-A ICE CREAM PAPER CONE FORMING MACHINE
Application:
The sucker will suck the pre-printed and cut paper from bracket to conveyor chain, then transfer it to forming mould. The paper will be sprayed with hot-melt glue. The position, length and amount of glue can be adjusted during production process without stopping the machine. The sprayed paper will be automatically blown out to the collector after formation, and the paper will be piled up and delivered out according to the settled number without stopping the machine.
Features:
1. High efficiency, max speed is 180pcs/min, and auto-counting the finished products.
2. Small size requires small space.
3. Easy to intall
4. Low power of 5.5 kw. Frequency controls the speed with high precise.
5. Box type structure transmission with good rigidity, stability and high precise. Oil circulation lubrication is adopted.
6. High automation, easy to operate and regulate and convenient maintenance.
7. Reasonable price. There are two types for option.
Technical specifications:
Model |
JXG-A(standard type) |
JXG-B(special order) |
Speed(pcs/min) |
Max. 180 |
|
Material |
Ordinary paper, composite aluminium foil paper, ≤120gsm dry stencil paper |
|
Optional parts |
1. Glue spraying control program 2. Air compressor |
|
Occupied area(m) |
2x2 |
|
Min height(mm) |
140 |
|
Max height(mm) |
220 |
255 |
Angle(degree) |
15~22 |
Customer requirement |
Weight(kg) |
1000 |
|
Dimension(mm) |
1250x1150x1900 1000x600x850 |
|
