Specifications
Thermal film laminator1.Suitable for thermal & gluess film
2.High spped up to 70m/min
3.Auto feeding & sheeting
Thermal film laminator
Applications:
This machine is used to realize the processing of thermal film lamination or gluess film lamination onto paper or carton. The machine is widely accepted in printing & packaging industry in home and abroad.
Features:
¨Servo controlled high speed feeder gives more accuracy and stability.
¨Whole machine adopts heat recycling system. It ensures high speed and cost saving.
¨Hot recycling oil, high pressure and smooth pressing cylinder allow high speed and give perfect lamination quality.
¨Double rotary disc type sheeters ensure perfect sheeting at high speed.
¨The machine is suitable for thermal and glues film lamination
Standard configurations:
¨Automatic feeder: Auto servo controlled adjustment of overlapping position; Accurate overlapping, low noise, high feeding precision.
¨Laminator host:
Auto temperature controller for recycle oil heating system features quick heating and temperature stability
Cold water cooling system:
Cold water system is especially good for thin paper. It ensures that there is no curling to thin paper after lamination.
¨Double rotary disc type sheeters (bouncing broken)
Double rotary disc type sheeters ensure perfect sheeting at high speed. It has compact structure and features space saving and easy operation.
¨Automatic stacker
It is suitable for thin and thick paper sheet delivery after lamination at high speed.
¨Non-stop feeding device
¨Pre-load device
¨Podwer removing device
¨Anti static system
Technical specifications:
¨Max.Lamination width: 1200mm
¨Max.Sheet size: 1200X950mm
¨Min.Sheet size: 350X350mm
¨Film thickness: 12-25um
¨Paper substrate: 80-600gsm
¨Laminating speed: 5-70m/min
¨Machine weight: 5200kgs
¨Total power: 27.82-36.82kw
Machine size: 9247X2408X1915mm(LxWxH)
