Plastic Dot IR Megapixel 6mm CS Lens 850TVL With IR CUT 30M Night Vision Surveillance Camera

Plastic Dot IR Megapixel 6mm CS Lens 850TVL With IR CUT 30M Night Vision Surveillance Camera thumbnail-1
Plastic Dot IR Megapixel 6mm CS Lens 850TVL With IR CUT 30M Night Vision Surveillance Camera thumbnail-2
Plastic Dot IR Megapixel 6mm CS Lens 850TVL With IR CUT 30M Night Vision Surveillance Camera thumbnail-3
Plastic Dot IR Megapixel 6mm CS Lens 850TVL With IR CUT 30M Night Vision Surveillance Camera thumbnail-4
Plastic Dot IR Megapixel 6mm CS Lens 850TVL With IR CUT 30M Night Vision Surveillance Camera photo-1
Plastic Dot IR Megapixel 6mm CS Lens 850TVL With IR CUT 30M Night Vision Surveillance Camera photo-2
Plastic Dot IR Megapixel 6mm CS Lens 850TVL With IR CUT 30M Night Vision Surveillance Camera photo-3
Plastic Dot IR Megapixel 6mm CS Lens 850TVL With IR CUT 30M Night Vision Surveillance Camera photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Zbravo
Model Number:
Z-CD1090Z
Contact Supplier Request Quote Chat Now
Shenzhen Zbravo Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen / Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Zbravo
Model Number Z-CD1090Z
Type Analog Camera
Style Dome Camera
Sensor CMOS
Technology Infrared
Special Features Other, Dot 30M IR Surveillance Dome Camera

Specifications

Plastic White Dome Camera CCTV Surveillance Camera
1 pcs* Dot IR-LED
IR Range 30M
850TVL With IR CUT
Megapixel 6 mm CS Lens

Plastic Dot IR Megapixel 6mm CS Lens 850TVL With IR CUT 30M Night Vision Surveillance Camera





Plastic Dot IR Megapixel 6mm CS Lens 850TVL With IR CUT 30M Night Vision Surveillance Camera





Model : Z-CD1090Z

CCD + DSP : PC3089

Horizontal Resolution : 850TVL,with IR-CUT

Pickup Device : 1/3"Super CMOS

Plastic Dot IR Dome Camera
1 pcs* Array IR LED
IR Range 30M
Built-in Megapixel 6 mm CS mount Lens
Color:White
Dimension : 94(H)*127(D) mm
Weight: 0.32KG





Model Z-CD1090T Z-CD1090Z Z-CD1090N Z-CD1090U Z-CD1090X
CCD + DSP PC1089 PC3089 PC1099 HD1080 138+FH8520
Image Sensor 1/4"CMOS 1/3"Super CMOS
Horizontal Resolution 550TVL 850TVL 900TVL 1100TVL 1200TVL
TV System PAL/NTSC
Image Resolution
(PAL / NTSC) 		728*488 756*504 976*496 1080*820 1296*1041
Lens Megapixel 6 mm CS mount Lens
Scanning System 2:1Interlace
Minimum illuminator 0.01Lux/F1.2
S/N Ratio >=48dB(AGG OFF)
AES 1/50-1/80,000sec(PAL),1/60-1/80,000sec(NTSC)
DNR No 3D
OSD No Yes
White Balance Auto ATW/Manual/Auto
AGC Auto Auto/Manual/Off
synchronization System Internal Synchronization
Video Output 1.0Vp-p,75Ω
Voltage DC12V (9V ~ 15V)
Operating Temperature —20℃~60℃ / 10% ~ 95%RH
