Information
1. Product name: EN IPE/IPEAA 80-200Hot rolled carbon steel H beam
2. Product Description
H beam IPE/IPEAA | |
Type: |
IPE/IPEAA |
Grade: |
SS400/Q235B/Q345 |
Application: |
Structural steel |
Length: |
5.8m/6m/12m OR according to customer requirements |
Size: |
8#-20# |
Steel type: |
Hot rolled carbon steel |
Standard: |
EN |
Zinc coating: |
80-600g.m2 |
Zinc type: |
hot dipped galvanized |
Further processing: |
Galvanization and slotted |
Standard |
Grade |
Chemical Compostiton(%) |
||||
C |
Mn |
Si |
S |
P |
||
≤ | ||||||
Q235 |
A |
0.14~0.22 |
0.30~0.65 |
|
0.05 |
0.045 |
B |
0.12~0.20 |
0.30~0.70 |
0.3 |
0.045 |
||
C |
≤0.18 |
0.35~0.80 |
|
0.04 |
0.04 |
|
D |
≤0.17 |
|
0.035 |
0.035 |
||
Mechanical Properties | ||||||
Standard |
Tensile Strength(MPa) |
Yield Point |
Elongation(%) |
|||
Q235 |
375~500 |
235 |
26 |
|||
Q345B Chemical Composition(%) | ||||
C |
Mn |
Si |
S |
P |
≤0.20 |
≤1.70 |
≤0.50 |
≤0.035 |
≤0.035 |
Q345B Mechanical Properties | ||||
Tension Strength |
Yield Point |
Elongation |
||
470-630 |
345 |
21 |
||
3. Size range: (If there is special size,please contact me,and different thickness has different tolerance,if the pipes are used for machine parts,it would be important for you to know the accurate tolerance,please feel free to ask me.)
H Beam (IPE)
Type |
H×B (mm) |
Web thickness (mm) |
Flange thickness (mm) |
GB Weight (kg/m) |
Available Length |
IPE80 |
80×46 |
3.8 |
5.2 |
6 |
6-12m |
IPE100 |
100×55 |
4.1 |
5.7 |
8.10 |
6-12m |
IPE120 |
120×64 |
4.4 |
6.3 |
10.4 |
6-12m |
IPE140 |
140×73 |
4.7 |
6.9 |
12.9 |
6-12m |
IPE160 |
160×82 |
5.0 |
7.4 |
15.8 |
6-12m |
IPE180 |
180×91 |
5.3 |
8.0 |
18.8 |
6-12m |
IPE200 |
200×100 |
5.6 |
8.4 |
22.4 |
6-12m |
H Beam (IPEAA)
Type |
H×B (mm) |
Web thickness (mm) |
Flange thickness (mm) |
GB Weight (kg/m) |
Available Length |
IPEAA80 |
78×46 |
3.2 |
4.2 |
4.95 |
6-16m |
IPEAA100 |
97.6×55 |
3.6 |
4.5 |
6.72 |
6-16m |
IPEAA120 |
117×64 |
3.8 |
4.8 |
8.36 |
6-16m |
IPEAA140 |
136.6×73 |
3.8 |
5.2 |
10.05 |
6-16m |
IPEAA160 |
156.4×82 |
4.0 |
5.6 |
12.31 |
6-16m |
IPEAA180 |
176.4×91 |
4.3 |
6.2 |
14.94 |
6-16m |
IPEAA200 |
196.4×100 |
4.5 |
6.7 |
17.95 |
6-16m |
4. Material: SS400,Q235,Q345
5. Zinc coating mass: 230-500g/m2(as your request)
6. Technical type: hot-rolled
7. Ends: End cutting(as your request)
8. Certification: BV, IAF, SGS,COC, ISO
9. Place of origin: Tangshan/Tianjin-China
10. Applications:For structure:bridge,Dock,road,building structure.
Packing
1. Packing:
In bundles,in bulk,plastic waterproof package or as your request.
2. Small diameter(measurement<weight):
Length≤5.8m,put in a 1*20FT with 25 tons max.
Length≤11.8m,put in a 1*40FT with 27 tons max.
3. Large diameter(measurement>weight):
5898*2300*2350mm: A 1*20 FT
12024*2300*2395mm: A 1*40 FT
Delivery
1.Trade terms:CIF,CFR,FOB
2.Payment terms:
(1)T/T 30% in advance,70% balance before delivery.
(2)L/C at sight.
3.Loading port:TianJin/shenzhen/foshan China
4.Cooperation ship-owner: MSK, CMA, MSC, HMM, COSCO, UA, NYK, OOCL, HPL, YML, MOL
5.Handing time:
(1)If the goods you need are special pipes,we need 3-5 days to purchase materials.
(2)Production capacity:our company can produce 500 tons a day at least.
(3)We need 5-7 days to do the post processing(packing,oil pented,cap installed),this is according to the client's requirements.
(4)We need 1-2 day to transport the goods to the loading port.
6.Specificed delivery date from the date of order:
25ton-100tons: usually 15 days after we receive your first payment.
100tons-500tons: usually 20 days after we receive your first payment.
More than 500tons: usually 25 days after we receive your first payment.
(Dear client,metimes we need a little more days to purchase and prepare materials or 2.If there are many orders some one month,we need a little time to arrange production.Both cases will make the delivery date later.)
Services for you
1.Certificates guarantee and our factory is open for you!
2.Samples free and we accept third party inspection .
3.Experience foreign trade team,we can deal with the problems in the foreign trade.
3.Our factorys located in TianJin and foshan,both are one hour's journey to the port,we can delivery goods on time.
5.Quality guarantee:
(1)In normal conditions,years of use is 20 years,except lots of sunshine,rain or corrosive liquid.
(2)We guarantee our goods with no damage and no bend.
(3)We accept your testing before shipment.
Our company group
| 1.Company Name: FOSHAN VANES TRADING CO.,LTD | ||||
| 2.Business area: | ||||
| Steel pipe Manufacture, Cold roll Manufacture,Trading | ||||
| 3.Main Products: | ||||
| steel weld pipe | special pipe | square tube | rectangular tube | |
| galvanized pipe | stainless tube | spiral welded pipe | tube shelf | |
| cold roll sheet | galvanized sheet | prepainted galvanized steel sheet | ||
| SPCC-SB/SD | H beam | I beam | Channel steel | |
| Rebar | stainless tube | stainless sheet | stainless roll | |
| 3.Owned factory: 3 Subsidiaries | ||||
| 4.Company location: Nanhai,Foshan city,Guangdong | ||||
| 5.Group's total number of employees: 600 people | ||||
| 6.Main Markets: Asia/Mid East/Europe/North & South Ameirca/Africa | ||||
Questions
1.What's the MOQ?
Usually our minimum order quantity: A 1*20FT(usually).
But we surely accept small order such as 1 ton,however the payment terms of the small order is 80% T/T first payment.
2.How to place an order?
A. Please send the accurate OD,THK,Length,Technical Standard and Material of the pipe you need to me.(by e-mail,or add my skype,whatsapp,or ask me on the trademanager.)
B. Then I will reply you the details you want.
C. We go on chatting with each other and realizing each other detailed requirements...
D. Any questions you can feel free to contact me,I will reply you within 24 hours.
E. We agree on all the issues,and we make a deal.
