China Jracking Adjustable Pallet Rack System
ADVANTAGES
<Economical>
High space utilisation to make the full use of your warehouse thus to SAVE THE COST OF STORAGE
<High Compatibility>
Designed for optimizing GOODS OF ALL SIZES AND WEIGHT
<High Selectivity>
Easy to install and dismantle. Mostly BOLT-FREE AND COMPONENT REPLACABLE
<Convenient For Storage Management>
Easy for INSTALLATION and simple to ADJUST
Pallet racking system provides a direct access to all pallets, and is the most economical choice in terms of cost. It is composed of upright frames and beams. Pallet racking is designed for optimizing storage of goods of all sizes and weights. With a wide range of components and accessories, JRACKING can tailor-make to meet your precise requirements. JRACKING structure is versatile for any application and conditions. Easy to install and dismantle.
Hex & Arch |
Section |
Thickness |
Weight Capacity |
Roll-out Tube |
Section |
Thickness |
Weight Capacity |
85x67mm |
1.8-2.3mm |
8,000-12,000Kgs |
80x50mm |
1.5mm |
500-3,800Kgs |
||
90x67mm |
1.8-2.3mm |
8,400-12,600Kgs |
90x50mm |
1.5mm |
650-4,300Kgs |
||
100x67mm |
2.0-2.5mm |
12,000-16,000Kgs |
100x50mm |
1.5mm |
800-4,500Kgs |
||
120x95mm |
2.5-3.0mm |
18,000-24,000Kgs |
110x50mm |
1.5mm |
950-4,500(+)Kgs |
||
Teardrop |
Section |
Thickness |
Weight Capacity |
120x50mm |
1.5mm |
1,100-4,500(+)Kgs |
|
3"x1 5/8" |
14Ga |
13,500lbs |
140x50mm |
1.5mm |
1,500-4,500(+)Kgs |
||
3"x3" |
14Ga |
21,000lbs |
160x50mm |
1.5-2.0mm |
2,000--4,500(+)Kgs |
||
3"x3" |
13Ga |
25,000lbs |
Mill Tube |
Height |
Thickness |
Weight Capacity |
|
3"x2 9/25" |
15Ga |
12,200lbs |
3" |
14-16Ga |
1,000-4,400lbs |
||
3"x2 9/25" |
14Ga |
13,600lbs |
4" |
14-16Ga |
1,900-7,000lbs |
||
4"x2 5/5" |
13Ga |
30,100lbs |
4 1/2" |
14-16Ga |
2,500-8,400lbs |
||
4 3/4"x 3 3/4" |
13Ga |
35,000lbs |
5" |
14-16Ga |
3,300-10,000lbs |
||
4 3/4"x 3 3/4" |
12Ga |
40,000lbs |
5 1/2" |
14-16Ga |
3,900-10,000lbs |
||
4 3/4"x 3 3/4" |
11Ga |
49,900lbs |
6" |
14-16Ga |
5,600-10,000lbs |
Jracking would never ignore the packaging and shipping at the very end of manufacturing work before loading products. We concern as much as our clients. Thanks to the experienced considerable and confidential logistics team, your products will be delivered fasten and safe.
Founded on Dec.,2012, NANJING JRACKING INTERNATIONAL LTD devotes itself to the design and manufacture of storage equipment. Through products and services aimed at providing complete assistance for all warehousing, product showcasing and sales outlet requirements. Since it established, as an excellent supplier which specializing in storage solutions and equipment, JRACKING has been managed with physical development policy. JRACKING builds a modern production workshop and strict production management. Each Jracking person pursues to understand customer needs fully and to create best benefits for customers.
Relying on the forefront of China's economic development – on the basis of rich human and material resources and technical force in the Yangtze river delta economic circle, Jracking has been set up million square meters production factory which is equipped with cold rolling, turning gold, machining, spraying production workshop. Jracking processes thousands of tons steel every year. Factory has excellent geographical and convenient transport environment in which located at Nanjing 80 kilometers to the east, adjacent to Shanghai, Wuxi, near to China's largest metal material distribution center, connect with the 312 national highway, shanghai-Nanjing expressway,
JRACKING aimed at developing with "continuous steady, absolute professional, high quality, high technology" as the development model continuously, becoming the world's influential storage shelves manufacturing enterprises, to be believed by both of customers and the employees as the most competitive and professional enterprise with excellent enterprise culture.
Business Specialist–Your Personal Consultant
Jracking offers one-stop services. Don’t bothering around communicating with a whole company. Once your request received, your personal assigned consultant will be ready to provide you help at any time. Over 20 years consulting experience advisers and expert-trained professional service team waiting for your orders.
Technical Engineer – Your Expert Backup
“How do I plan my warehouse”, “Which kind of equipment is suitable for my storage requirement”? Such kind of trouble can be perfectly resolved by our technical engineer team. Jracking devotes to serve on the view of customer. Once your basic data, project drawing or the specifications of the product provided, the best solution will be carried out by our technicians.
You might concern:
1.Does Jracking have MOQ (minimum order quantity) limitation?
No, but good quantity comes with good price. We recommend the order quantity for regular products of Jracking to fit at least one 20ft. container, which is about 15 tons.
2.What is Jracking’s lead time?
For the order quantity fitting one 20ft. container is about 15 days. Lead time of highly-customized products should rely on the actual production.
3.What trade and payment term does Jracking offer?
EXW, FOB and CIF are the most commonly used trade terms in Jracking, and we offer T/T, L/C, D/P payment terms.
4.How does Jracking charge tooling fee (cost of opening new mold)?
For the production of necessary tooling requirement, Jracking charges the cost before the first order for opening new mold, and the cost will be partially or fully refunded after certain quantity of orders.
5.What warranty does Jracking offer?
For break or damage of goods caused by non-human or incorrect installation factors (except for force majeure), namely, by natural reasons which concluded as quality failure within 1 year after delivery, Jracking offers free replacement service.
6.What information do I need to provide before sending my request for quote?
- Dimension (height, length, width) and weight of well-packed/palletized goods, or the size and load capacity of racking (system);
- Dimension (height, length, width) of warehouse/storage area for system designing, or the original construction drawing if you have;
- Proposed width of aisle or accessing automobile (such as forklift);
- Proposed number and heights of floors for mezzanine rack and steel platform.
PS: Height is very important for designing, which sometimes Jracking’s clients would forget to provide this specification. The more exact information you can provide the easier and more accurate for engineers to calculate and design, thus the final solution would be more suitable for your situation. Jracking thank you for all your dedicate cooperation!
