Hydraulic hose pipe
- 1000 Meter / Meters per Month
- TIANJIN
- T/T L/C D/P D/A Credit Card
Product Details
Place of Origin: | Hebei, China | Brand Name: | MINGHOSE | Model Number: | R1 R2 R3 R4 R5 R6 R12 R13 |
Product Description
Hydraulic hose pipe
SAE 100R3/EN854
Double Fiber Braid (nonmetallic ),Rubber Covered Hydraulic Hose
Tube: Oil Resistant synthetic rubber
Reinforcement: Two high tensile fiber braid (2T/B)
Cover: Abrasion and weather resistant synthetic rubber
Temperature Range: -40 ℃ to +100℃
DN | ID | OD | Working Pressure | Burst Pressure | Minimum Bend Radius | Weight | |||
| inch | mm | mm | Mpa | PSI | Mpa | PSI | mm | kg/m |
5 | 3/16 | 4.8 | 13.4 | 41.4 | 6000 | 165 | 23720 | 89 | 0.32 |
6 | 1/4 | 6.4 | 15.0 | 40.0 | 5800 | 160 | 22840 | 102 | 0.36 |
8 | 5/16 | 7.9 | 16.6 | 36.0 | 5250 | 140 | 20000 | 114 | 0.45 |
10 | 3/8 | 9.5 | 19.0 | 33.1 | 4800 | 132 | 18840 | 127 | 0.54 |
13 | 1/2 | 12.7 | 22.2 | 27.6 | 4000 | 110 | 15720 | 178 | 0.68 |
16 | 5/8 | 15.9 | 25.4 | 25.0 | 3630 | 100 | 14280 | 203 | 0.8 |
19 | 3/4 | 19.0 | 29.3 | 21.5 | 3120 | 85 | 12280 | 241 | 0.94 |
25 | 1 | 25.4 | 38.0 | 16.5 | 2400 | 65 | 9420 | 305 | 1.35 |
32 | 1 1/4 | 31.8 | 48.3 | 12.5 | 1820 | 50 | 7140 | 419 | 2.15 |
38 | 1 1/2 | 38.1 | 54.6 | 9.0 | 1310 | 36 | 5140 | 508 | 2.65 |
51 | 2 | 50.8 | 67.3 | 8.0 | 1160 | 32 | 4560 | 635 | 3.42 |
SAE 100R6
Fiber Reinforced (nonmetallic), Rubber Covered Hydraulic Hose
Tube: Oil resistant synthetic rubber
Reinforcement: One layer of suitable fiber
Cover: Oil and weather resistant synthetic rubber
Temperature Range: -40℃.to +100℃
DN | ID | OD | Working Pressure | Burst Pressure | Minimum Bend Radius | Weight | |||
| inch | mm | mm | Mpa | psi | Mpa | psi | mm | kg/m |
5 | 3/16 | 4.8 | 11.1 | 3.4 | 500 | 13.8 | 2000 | 50 | 0.11 |
6 | 1/4 | 6.4 | 12.7 | 2.8 | 400 | 11.0 | 1600 | 65 | 0.15 |
8 | 5/16 | 7.9 | 14.3 | 2.8 | 400 | 11.0 | 1600 | 75 | 0.16 |
10 | 3/8 | 9.5 | 15.9 | 2.8 | 400 | 11.0 | 1600 | 75 | 0.18 |
13 | 1/2 | 12.7 | 19.8 | 2.8 | 400 | 11.0 | 1600 | 100 | 0.26 |
16 | 5/8 | 15.9 | 23.0 | 2.4 | 350 | 9.7 | 1400 | 125 | 0.29 |
19 | 3/4 | 19.0 | 26.6 | 2.1 | 300 | 8.3 | 1200 | 150 | 0.4 |
1. We consistent good quality with reasonable price.
2. Stable production capacity(Our output each month can be 800,000 meters for hoses.)
3. Delivery in time.
4. Good quality control.
