Specifications
* Support 3G Function* Support 2 HDD
* With HDMI
Product features:
* H.264 Main Profile video compression mode
* 24 CIF recording 4CIF playback
* with domain name, plug-and-play, network access super simple
* support for HDMI HD output, 1080P resolution, the image more clearly
* powerful stable mobile phone monitoring functions, support for Windows Mobile, Symbian, Android, iPhone, Blackberry mobile phone operating system
* support for IE browsing and control software in the centralized supervision and management network multiple DVR (can simultaneously monitor 255)
* built-in speaker with the network client communication more convenient
* support multiple users simultaneously online monitoring
* support for dual stream, video and network can set different parameters
* support for digital watermarking encryption, secure and reliable
* support for 3G, WIFI wireless network
* support for various network protocols SMTP, UPNP, DDNS, PPPOE etc.
* external trigger alarm, support E-mail linkage sending alarm information and screenshots
* six operators: preview, video, playback, backup, network monitoring and mobile phone monitoring can be carried out independently
* supports up to 28 languages
* a new graphical interface, independent design, has a good user experience
SPECIFICATION |
AT-5024E |
Video System |
NTSC / PAL |
Video Compression Format |
H.264 |
Video Input |
24 Channels. Composite video signal 1 Vp-p 75Ω BNC |
Video Output |
Main Monitor Output: Composite video signal 1 Vp-p 75Ω BNC |
Maximum Recording Rate |
D1:400IPS |
Hard Disk Storage |
SATA type, supported HDD*4, support each HDD capacity over 16TGB |
Recording Mode |
Manual / Timer / Motion / Alarm / Remote |
Refresh Rate |
D1:400IPS |
Multiplex Operation |
Live display, record, playback, backup and network |
Audio I/O |
8audio inputs, 1 audio outputs |
Backup Device |
USB2.0 flash drives ,network ,HDD |
Web Transmitting / Compression Format |
H.264 |
Ethernet |
10/100 Base-T. Support remote control and live view via Ethernet. |
Web Interface |
Support licensed software AP, and IE browser |
Network Connection |
TCP/IP, PPPoE, DHCP and DDNS |
Remote Control |
Remotely control DVR and PTZ cameras via IR transmitter |
PTZ control |
Support PELCO-D protocol |
Picture Zoom |
Support 2X digital zoom function |
Alarm I/O |
8 inputs, 1 output |
Multilingual OSD |
Yes |
Watermark |
Yes |
Support 3G WIFI GPRS |
Yes |
Key Lock |
Yes |
Video Loss Detection |
Yes |
Power Source |
220V |
Power Consumption |
30W without HDD |
Operating Temperature |
-10°C ~ 60°C |
Dimensions (mm) |
370(W) x60(H) x 300(D) |
System Recovery |
System auto recovery after power reconnected |
