Top10! 1.0M Network Box IP Camera
US$ 39 - 41
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ANTAI
Model Number:
ipc-1171
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
ANTAI
Model Number
ipc-1171
Type
Digital Camera
Style
Box Camera
Sensor
CMOS
Technology
NetWork
Special Features
Other, HD camera
Specifications
Image Sensor: 1/4" COMSResolution: 1280*720
Effective pixels: 1 Mega pixels
Video Compression: H.264
Product Description
| FEATURES | ||
| Preview and compression resolutions are both 1280*720; | ||
| Totally developed Cloud technology is embedded in network remote surveillance. No need for complex setting; network transmission is convenient; | ||
| Supports triplex streams, and users could select streams and adjust resolution and stream according to needs; | ||
| Supports IR-CUT, double light filter automatical switching, realizing night vision; | ||
| Supports motion detection and sending mail alert automatically; | ||
| Supports software updating from website or local; | ||
| Supports network parameters static setting/DHCP/ADSL; | ||
| Supports mobile monitoring, and picture quality and frame rate could be adjusted. No need for complex setting; | ||
| Supports screen motion detection and region cover. 4 different regions could be setted; | ||
| Supports restart after power off or accident problem; | ||
| Supports modifying system time and OSD content; | ||
| Supports real-time remote monitoring, remote starting host-end recording, remote recording playback and remote downloading; | ||
| Supports network user management, network time synchronization, CC, WebCC; | ||
| Surveillance system software, IE explorer and mobile could be selected as client-end. Various ways and high connection rate; | ||
| User manage, watch and record through self-developed Cloud surveillance system. | ||
| SPECIFICATIONS | ||
| 1MP (3518+OV9712) | ||
| Display | Image Sensor | 1/4" COMS |
| Resolution | 1280×720 | |
| Effective pixels | 1 Mega pixels | |
| Video Compression | H.264 | |
| Frames per second | 25fps | |
| Bitrate | 128Kbps~8Mbps | |
| Sync System | Internal | |
| S/N | 39dB | |
| Min. Illumination | 0Lux (IR ON) | |
| Lens | Interface | CS |
| Lens | 4mm, 6mm, 8mm, 12mm, 16mm optional | |
| Angle | 4mm:72°, 6mm:48.8°, 8mm:37°, 12mm:24.2° | |
| Focus | Manual | |
| Function | Privacy mask | Support 4 area privacy mask |
| Exposure control | Auto | |
| AGC | Auto | |
| Dynamic range | 69dB | |
| AWB | Auto | |
| Day/night | Auto, dual IR-Cut filter | |
| Video Adjustments | Contrast, Brightness, Saturation, Acutance | |
| Expansion Interface | NO | |
| Remote control | System, Streaming, Account, Network | |
| Motion Detection | YES | |
| Alarm | E-mail, Client software | |
| RS-485 protocol | NO | |
| Network | Ethernet | 10/100M BASE-TX,RJ-45 connector |
| Streaming | Three kinds of stream | |
| Protocol | HTTP,TCP/IP,ICMP.RTSP,RTP,UDP,RTCP,SMTP, FTP,DHCP,DNS,PPPOE |
|
| Transmit | P2P(plug and play), automatic port forwarding | |
| Enviornment | Operating Temperature | -20°C~+55°C |
| Operating Humidity | 10%~90% | |
