Home > Auto, Motorcycle Parts & Accessories > Car Safety > Car DVR > 8CH 1080P Realtime Playgback Dvr
8CH 1080P Realtime Playgback Dvr
US$ 33.00 - 33.00
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ANTAIVISION
Model Number:
HY-MH-4908
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
4CH1080P AHD DVR Support Audio, P2P, CMS and Alarm Full HD CCTV DVRUS$ 25.00 - 25.00MOQ: 1 Piece -
New Products AHD DVR 4CH 1080P Real Time DVR RecorderUS$ 25.00 - 25.00MOQ: 1 Piece
-
2016 Hot New Ahd Dvr 1080p 4ch Channel Dvr Home Cctv Outdoor SecurityUS$ 25.00 - 25.00MOQ: 1 Piece
-
1080P Real-time Playback DVR Use for AHD,IPC,Analog All in One CCTV DVR Security Camera System 4ch h 264 DVRUS$ 25.00 - 25.00MOQ: 1 Piece
-
LINUX Operating System DVRUS$ 25.00 - 25.00MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
ANTAIVISION
Model Number
HY-MH-4908
8CH 1080P realtime playgback dvr
Image:
8CH 1080P realtime playgback dvr Specification:
| System | Main processor | Industrial grade embedded micro controller chip Taiwan Zhiyuan chipset GM8210 | |
| Operating system | Embedded LINUX operating system | ||
| System resource |
Multi-channel real-time recording synchronously, multi-channel real-time playback, multi-channel multi-user network operation, USB back up. |
||
| Display | Operation interface | 16 bit real color GUI interface support mouse operation | |
| Multilingual Language | YES, 25 kinds of language | ||
| Display screen | 1/4/8/9 screen | ||
| Video | Video Standard | PAL / NTSC(1080P) | |
| Image encode | H.264(Main Profile) | ||
| Capture function | YES | ||
| Monitor quality | Monitor:D1; VGA & HDMI: (1920*1080,1280*1024,1280*720,1024*768) | ||
| Playback quality | 1080P/720P | ||
| Encode capability | 8ch 1080P@15fps | ||
| Decode capability | 4ch 1080P@15fps | ||
|
Multi-Input (ONVIF 2.8) |
Analogue:8ch 1080P | ||
| Analogue+ Network HD:——— | |||
| Network:——— | |||
| Audio | Audio compression | G.711A | |
| Record and playback | Record mode | Manual, alarm, motion detection, timing | |
| Local playback | 1--4ch (local mode) | ||
| Video search | Time, date, event, channel search | ||
| Storage and back up | Space Usage | Video 720P:10G~42G/day*channel,1080P:20G~80G/day*channel,Audio 691.2M/day *channel | |
| Video storage | Local Hard Disk, Network | ||
| Back up mode | Network backup, USB portable HDD | ||
| Interface | Video input | 8ch BNC(1.0Vp-p,75Ω) | |
| Video output | 1ch CVBS, 1ch VGA, 1ch HDMI | ||
| Audio input | 8ch RCA (200-2800mV,30KΩ) | ||
| Audio output | 1ch RCA (200-3000mV,5KΩ)/1ch HDMI audio output | ||
| Alarm input | No | ||
| Alarm output | No | ||
| Network port | 1*RJ45 10/100 Base-T self-adaptive Ethernet port | ||
| PTZ control | 1*RS485 port, Support more than 20 kinds protocols. | ||
| USB port | Support USB 2.0 port | ||
| HDD port | Accommodates 1 SATA HDDs (Maximum support two, each of the maximum support 4TB) | ||
| Wireless Port | 3G & WIFI ( Extented by USB) | ||
| User | User level | Admin / User | |
| User right | Users can set different permissions (How to use please refer to the manual book) | ||
| Password protection | YES | ||
| Remote | Remote Independent Operation | YES | |
| Download records | YES | ||
| Remote Event Trigger Recording | YES | ||
| CMS | CMS Software for multiple DVR (up to 255 DVR simultaneously) | ||
| Browser | Internet Explorer, Mozilla Firefox, Google Chrome, Safari | ||
| Live Audio | YES | ||
| On-line user | Max. 10 | ||
| Mobile Surveillance | YES (supporting iPad, iPhone & Android;iPad, iPhone, Andriod remote playback) | ||
| Network Protocol | DHCP, PPPOE, FTP, DDNS, NTP, UPNP, EMAIL, IP authority, 3G, Wireless settings | ||
| Alarm | Motion detection | 16 × 12 grids per channel;6 adjustable parameters for accurate detection(for local analog channel only) | |
| Event Notification | FTP / E-Mail | ||
| Pre-alarm Recording | YES | ||
| Video loss | Video loss notification | ||
| Buzzer | YES | ||
| Others | IR remote controller | Remotely control DVR and PTZ cameras via IR transmitter (IR receiver built-in) | |
| Remote control | YES | ||
| Cooling fan | NO | ||
| Tour | YES | ||
| Power Source (±10%) | DC 12V / 3A | ||
| Power Consumption (±10%) | <10W(without HDD) | ||
| Operating Temperature | 0℃ ~ +55℃ | ||
| Dimensions (mm) ** | 325mm(L)* 245mm(W)* 52mm(H) | ||
| System Recovery | System auto recovery after power failure | ||
| Package | Net Weight | 1.45kg±0.1kg | |
| Carton Box Size | 350mm(L)* 110mm(W)* 305mm(H) | ||
| Package Size | 570mm(L)* 367mm(W)* 326mm(H) | ||
| Gross Weight | 12.0kg±0.5kg | ||
Packaging & Shipping
Company Information
Exhibition
Certification
Our Services
After sales service:
We offer 3 years warranty and whole life support:
1.software:we establish a neutral software website so that customer can go there to download all of the upgrade software by themselves.
2.hardware:we offer complete reparation book and offer free electronic components for your reparation.
Customized service:
The most important is we offer customized service so that you can valued your brand:
1.Unique hardware design(including front pannels,mainboard,color box ect)
2.Unique software design(including UI,APP,additional special software)
If you would like to know more about us and to be our partners in the near future,
pls feel free to contact with us and visit our factory.
