Specifications
Power supply Surge protection device 60KA / SPD / fall protection device1. CE & test report
2. Temperature:-40 ~-65
Power supply Surge protection device 60KA / SPD / fall protection device
DGM-type surge protector(hereinafter referred to as SPD)adapted to AC,mainly used for rated voltage not exceeding 1000V(RMS),200/380V,50/60Hz power supply system,not exceeding 1500V DC voltage of the circuit and equipment of the Surge Protection.SPD has a phase to phase(L-L),phase to ground(L-NE),phase to neutral(L-N),neutral to ground(N-PE) and combinations such as protected model.
· DGM-based high quality surge protector to use non-linear components and low residual voltage,small discharge current,modulus,and using safely and reliablely,designed and manufactured in accordance with the standards GB18802.1-2002/IEC61643.1,products have passed CE Certification and the national test Room:Beijing Lightning Experimental Device Type Detection Centers.
The DGM-B100/4 exact technology parameter is as below:
Type No. |
DC Power voltage |
Continuous Voltage Uc(V~) |
Standard Discharge Current In(KA) |
Max Discharge Current Imax(KA) |
Protection Level(KA~) |
|
DGM-B100/4 |
220/380
|
275/320 385/420
|
100 |
150 |
3.2KV |
|
Technology SPD parameter(Note:According to user requirement ,can be customized Uc=140V,440V,550V,voltage range of range of the SPD):
Type No. |
Rated Voltage(V) Un |
Continuous Voltage Uc(V~) |
Standard Discharge Current In(KA) |
Max Discharge Current Imax(KA) |
Protection Level(KA~) |
Response Time(ns) |
DGM1(2)-D5 |
220/380 |
275/320 385/420 |
5 |
10 |
1.2 |
≤25 |
DGM1(2)-D10 |
10 |
2 |
1.6 |
|||
DGM1(2)-C20 |
20 |
40 |
1.8 |
|||
DGM13-B30 |
30 |
60 |
.2.2 |
|||
DGM3(4)-B40 |
10 |
80 |
2.4 |
|||
DGM(4)-B60 |
60 |
100 |
2.8 |
|||
DGM-N-PE |
220/255 |
40/60 |
60/80 |
1.2 |
≤100 |
Part of DC power surge protection technology parameters:
Type No. |
DC power system Voltage(V) Un |
Continuous Voltage Uc(V~) |
Standard Discharge Current In(KA) |
Max Discharge Current Imax(KA) |
Protection Level(KA~) |
DGM-D5-Z/12 |
12 |
16 |
5 |
10 |
120 |
DGM-D5-Z/24 |
24 |
32 |
5 |
10 |
150 |
DGM-D5-Z/48 |
48 |
62 |
5 |
10 |
250 |
DGM-D5-Z/110 |
110 |
140 |
5 |
10 |
500 |
DGM-D10-Z/12 |
12 |
16 |
10 |
20 |
150 |
DGM-D10-Z/24 |
24 |
32 |
10 |
20 |
200 |
DGM-D10-Z/48 |
48 |
62 |
10 |
20 |
300 |
DGM-D10-Z/110 |
110 |
140 |
10 |
20 |
600 |
DGM-C20-Z/48 |
48 |
62 |
20 |
40 |
350 |
DGM-C20-Z/110 |
110 |
142 |
20 |
40 |
650
|
