OBO Lightning Surge Arrester
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
DGMDQ
Model Number:
DGM1-C20/4
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Class C Surge ProtectorUS$ 28 - 30MOQ: 1 Piece -
Surge Protector(SPD) / Surge Protective Device /CENegotiableMOQ: 1 Piece
-
Power Surge Protector(SPD)US$ 18 - 20MOQ: 1 Piece
-
Good Quality 1+NPE Power Surge Protection With Float SwitchUS$ 10 - 12MOQ: 1 Piece
-
Good Quality Voltage Surge Protector Clase b With ISO9001:2008US$ 23 - 25MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
DGMDQ
Model Number
DGM1-C20/4
Specifications
OBO Lightning Surge Arrester1, CE Certification & Test Report
2, Class C, 220v surge protector
Product introduce and application:
- DGM-type surge protector(hereinafter referred to as SPD)adapted to AC,mainly used for rated voltage not exceeding 1000V(RMS),200/380V,50/60Hz power supply system,not exceeding 1500V DC voltage of the circuit and equipment of the Surge Protection.SPD has a phase to phase(L-L),phase to ground(L-NE),phase to neutral(L-N),neutral to ground(N-PE) and combinations such as protected model.
- DGM-based high quality surge protector to use non-linear components and low residual voltage,small discharge current,modulus,and using safely and reliablely,designed and manufactured in accordance with the standards GB18802.1-2002/IEC61643.1,products have passed CE Certification and the national test Room:Beijing Lightning Experimental Device Type Detection Centers.
The DGM1-C20/4 exact technology parameter is as below:
Type No. |
Rated Voltage(V) Un |
Continuous Voltage Uc(V~) |
Standard Discharge Current In(KA) |
Max Discharge Current Imax(KA) |
Protection Level(KA~) |
Response Time(ns) |
DGM1(2)-C20 |
220/380 |
275/320 385/420 |
20 |
40 |
1.8 |
≤25 |
Key words : Surge Protective Device(SPD) / 220v surge protector / class C, Surge Protection,Surge Protector,Surge Arrester,Surge Suppressor,Lightning Surge Protector,Surge Protecton Device,Lightning Protection,Distribution Surge Protection,Lightning Arrester and so on
