Specifications
1, no spark2, high wear resistance
3, high temperature
4, corrosion resistance
5, crash protection
We are a professional productions base of series ofrock drilling tools,mining tools,DTH Drill nstruction tools andexcavating coal pick cutter tools,we can also produce other products accordingto the customers requirements.we sincerely welcomes friends of both home andabroad to come for business talks.
Extension drilling tools
Button bit,face design:Flat face,drop centre,Normaland retrac body.
tungsten carbide(Buttons):Spherical,ballistic andConical.(Threaded R32,T38,T45,T51,bit diametre:45mm-127mm);
Couplings sleeves-manufactured with a middle stop toprevent walking along the thread.Include couplings sleeve(threaded R22,R25,R28,R32,R38,T38,T45,T51)
Shank adaptors-carburized and manufactured with tighttolerances and controlled straightness.
Used in extension rod connection, its function is to transmit impact energy from the rock-drill piston, as well as rotation torque, into the drill string with no losses. It must withstand and transmit up to 6300 blows per minute from the piston continually, with great endurance and dependability.
(1) Size: R25, R28, R32, R35, R38, T38, T45, T51, R25-R28, R22-R25, R25-R32 R32-R38, R32-T38.
(2) Length: 140mm-235mm
(3) Package: In wooden case or in carton.
(4) Productivity: 5000PCS/ month
Shank rods, drifter rods, couplings, shank adapters and drill bits. Drifter rods have a powerful male thread at the impact end, and a smaller male thread at the bit end. MF drifter rods have a female thread at the impact end and are threaded to the shank adapter directly. Drill bits range typically from 35 to 57 mm in diameter. This product group also includes reaming equipment for drilling large-diameter relief holes in the cut.
Product Name: |
rock drill coupling sleeve |
Description: |
rock drill coupling sleeve |
Material: |
Alloy steel bar |
MOQ: |
No MOQ required for testing and trial order |
Type |
full-bridge,semi-bridge,same diameter etc |
Thread type |
R22,R25,R28,R32,R38,T38,T45,T51 |
Diameter |
33mm-76mm |
Length |
140mm-250mm |
Color |
Gold, Black |
1. According to the technical drawings using standard material specification production
2. Competitive price and products
3. tungsten carbide with reinforcement coal mining drill bits
ntinuous miner, long wall shearing, roadheader
Liaocheng Kaituo Construction machinery Co.,Ltd headquartered in Yanggu, Shandong, incorporating manufacturing, trading and customer service in global mining and engineering construction, services for global mining and civil engineering construction.
Payment: T/T, 30% in advance, 70% before shipment.
Delivery time: about 15-20 days.
