Shenzhen Supply 7dBi 1920-2170MHz 3G GSM External Antenna Amplified Car Patch Antenna
- Shenzhen
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
-
High Power 1920-2170MHz 9dBi Patch Antenna Omni Directional High Gain 5.8GHz Patch Antenna With SMA
-
Professional Manufacturer 1920-2170MHz 9 DBi Antenna For Huawei Long Range 3G Rubber Antenna
-
Signal Strength 850-1900MHz Indoor Rubber Antenna Omni 1.2G Rubber Duck Antenna With Right Angel SMA
-
Signal Strength Mini Flexible Antenna SMA Connector High Gain 3g Rubber Duck Antenna
-
CDMA Panel Antenna 12dbi 20cm Cable N Female or Customize
-
13dbi CDMA Antenna Magnetic Mount 13dB SMA Connector/adapter
Product Details
| Place of Origin | Guangdong, China | Brand Name | Yetnorson | |
| Model Number | YXN-0232- Amplified Car Patch Antenna |
One product with one PE bag package of Amplified Car Patch Antenna
Product Description
Specifications
Amplified Car Patch Antenna1) High Gain 7dBi
2) Frequence:1920-2170MHz
3) Factory price
4) CE,RoHs,ISO
| Electrical Specifications of Amplified Car Patch Antenna | |
| Frequency Range (MHz) | 1920-2170MHz |
| Input Impendence (Ω) | 50 |
| V.S.W.R | ≤1.2 |
| Gain (dBi) | 7dBi |
| F/B Ratio | ≥15dB |
| Horizontal Beam width | 60°-90° |
| Vertical Beam width | 70°-70° |
| Polarization Type | Vertical |
| Power Capacity (w) | 100 |
| Mechanical Specifications | |
| Antenna Dimension | 210mm*180mm*45mm |
| Connector | SMA |
| Weight | 0.6kg |
| Mounting Mast Diameter | Ø30~Ø50mm |
| Rated Wind Velocity | 210Km/h |
| Operating Temperature | -40°C to+80°C |
| Radome Material | UV protected ABS |
| Radome Colour | black |
| Storage Temperature | -65°C to+85°C |
Welcome come to our website select your satisfied products ,if you have any question about our products pls feel free contact us we are always be ready anytime!!!
Company Profile
Shenzhen Yetnorson Technology Co.,Ltd is one of professional antenna maker, which focus on GSM/CDMA/PHS/3G/4G antenna, 2.4GHz (wi-fi, wlan)/3.5GHz (wimax)/5.8GHz/wi-fi amplifier communication antenna serial(including: all direction, yagi antennas ,3G parabolic antennas, panel antenna, indoor antenna like : ceiling mount antenna, Wall Mount Antenna, desk antenna, double polar, rubber, bandwide, card mount serial antenna. We also provide DVB-T/DMB-T/CMMB moving digital TV antenna, low frenquency antenna: 315MHz/433MHz wi-fi digital /wi-fi control /wi-fi wrote water meter/electricity meter antenna, GPS guide antenna, communicate parts, connector and so on. At present, Shenzhen Yetnorson Technology Co.,Lth.has developed more than 100 styles of antenna, with wi-fi internet, wi-fi electronic control, wi-fi end, wi-fi public telephone, wi-fi digital pass, wi-fi Satilla position, wi-fi Radio broadcasting communication field. We offer antennas with good quality and good price. And we are cooperating with several overseas clients from all over the world. Please support us. Thank you very much!
