single screw tire retreading equipment

FOB Price

USD $50,000 - $500,000 / Set

1 Set(Min.Order)

Supply Ability 10 Set / Sets per Month
Port Qingdao port
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Place of Origin:	Shandong, China	Brand Name:	Zhihong
Model Number:	XJD-200x12D-Y	Voltage:	220V-460V	Power(W):	280kw
Dimension(LWH):	4900x1900x1850mm	Weight:	14000kg	Certification:	ISO9001 CE
Warranty:	12 months	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

single screw tire retreading equipment

equipment for cold retreading

hot sale tire retreading equipment

1. Application:
the pin barrel rubber extruder is mainly used for the shaping extrusions of rubber compounds at room temperature. when fitted with different extruder heads, it can achieve many rubber products in rubber industry, for example, extruding of inner tubes and tire treads, coating of rubber tube and conveyor belt, shaping extrusion of profiles of rubber sheet and plate. in addition, it also incorporates into a multiple extrusion unit together with other (hot or cold feed) rubber extruders.
pin barrel extruder has good plastifying and mixing properties which can result in uniformity goods, low extrusion temperature , high extrusion capacity , low power consumation, wide processing adaptability.

2. Technical specifications:

Data / Model		XJD- 90X14D	XJD- 120X14D	XJD- 150X16D	XJD- 200X12D	XJD- 200X16D	XJD- 250X12D	XJD- 250X16D
Diameter Of screw(mm)		90	120	150	200	200	250	250
L/D		14:1	14:1	16:1	12:1	16:1	12:1	16:1
Max. speed of screw(r/min)		60	50	43	33	33	26	26
Size of feeding hopper (LxW) (mm)		120x80	160x110	200x165	260x210	260x210	340x208	340x208
Row quantity of pins		8	10	10	8	12	10	12
Pin quantity per row		6	6	8	10	10	12	12
Hot water circulating zones		3	3	4	4	4	4	4
Total power for hot water heating		24	36	48	48	54	48	48
Capacity (kg/h)		360	1000	1800	2600	2600	3000	3000
Motor power (kw)		55	90	220	280	315	400	450
Overall dimension(mm)	L	2300	3250	3880	4900	6200	5400	6077
	W	950	1250	1700	1900	1900	2400	2400
	H	1450	1650	1700	1850	1850	1920	1920
Weight (kg)		3250	5670	7250	14000	14600	18000	20800

Contact Us

Qingdao Zhihong Rubber Machinery Co., Ltd.: Contact nameMeihua Zhang; Phone0086-0532-85167976; AddressNo. 318, Zhaizishan Road, Huangdao Dist.
