YEESO 2014 Top Sale LED TV Trailer YES-T12 Outdoor Mobile Advertising Vehicle
Leading Manufacturer & Solution Provider of Mobile LED Advertising Vehicles
YEESO 2014 Top Sale LED TV Trailer YES-T12 Outdoor Mobile Advertising Vehicle:
1.It could be moved to anywhere as you like
2.Easy maintenance and operation
3.With screen lifting system
Model |
YES-T12 |
||||
Chassis | |||||
Brand |
Yeeso |
External dimension |
6600mm×1820mm×2650mm |
||
Material |
16# manganese steel |
sheet metal structure |
1.2mm plate steel |
||
Tire |
650 rubber tire |
Gross mass |
4750KG |
||
Brake |
Manual and Hit hydraulic brake |
minimum turning diameter |
≤18000mm |
||
Scissor Type Hydraulic Lifting Platform and support system | |||||
Hydraulic lift platform |
Lifting type:Scissor,Platform size:3200mm×750mm×400mm Lifting height:2000mm,load bearing :5T |
||||
|
Supporting system
|
leading screw supporting legs system, Lifting height: 300mm,each afford 5T,its wind-proof level can reach to maximum level 8 when screen is lifted up |
||||
LED screen | |||||
Screen size |
4800mm×2400mm=11.52 sqm |
Module size |
160mm(W) ×160mm(H) |
||
Chip |
R: Guanglei,G,B:Silan |
Pixel pitch |
10 mm |
||
Brightness |
≥6000cd/ sqm |
Max power consumption |
1200 W/ m |
||
Average power consumption |
600W/ m² |
Life span |
100,000hour |
||
Power supply | |||||
Input voltage |
three-phase five-wire 380V |
Output voltage |
220V |
||
Electrical current |
50A |
Power consumption |
average:0.5wh/sqm |
||
Multi-media control system | |||||
Industrial PC |
Processor: Dual Core CPU, display card:512,hard disk:320G,CD-ROM:DVD, internal storage:2G |
||||
Monitor |
KVM 15-inch LCD display |
Power amplifier |
unilateral power output:200W |
||
Speakers |
Max power consumption:200W |
Control system of LED screen |
Linsn/ZHOGNQING(The patent technology of point by point correction) |
||
YEESO 2014 Top Sale LED TV Trailer YES-T12 Outdoor Mobile Advertising Vehicle:
