Leading Manufacturer & Solution Provider of Mobile LED Advertising Vehicles
New Product Advantages of YES-TB16 Outdoor Mobile Led Advertising Vehicle:
1. The led screen could be rotated in 360 degrees
2. The screen could be folded and hidden inside the vehicle
3. It is environment-friendly product
4. It could work under bad weather circustances
Technical Parameters of New Product Advantages of YES-TB16 Outdoor Mobile Led Advertising Vehicle:
Model | YES-TB16 | |||||||
Chassis | ||||||||
Brand | YEESO | External dimension | 7900mm×2100mm×2800mm | |||||
Material | 16 manganese steel | Sheet metal structure | 1.5mm plate steel | |||||
Tire | Solid tire | Gross mass | 8100KG | |||||
Brake | Manual and Hit hydraulic brake | minimum turning diameter | ≤12000mm | |||||
motor power | 6.5KW | mileage range | 40-60KM | |||||
Rolling door type protective cover | ||||||||
External Dimension | 5150mm×3100mm×2 | Material | high-strength aluminum alloy | |||||
verticality error | 5° | horizontal error | 50mm | |||||
Power | speed adjusting motor | Sporty Structure | 3mm steel wire | |||||
Hydraulic lifting & supporting system | ||||||||
Hydraulic lifting system for LED screen | Lifting height:2000mm,afford 3T | |||||||
Hydraulic supporting system | leading screw supporting legs system, It can goes up 300mm,each afford 5T,its wind-proof level can reach to maximum level 8 when screen is lifted up | |||||||
Slewing mechanism | ||||||||
rotation angle | 360° | structure | slewing ring | |||||
LED screen | ||||||||
Screen size | 4800mm×3200mm | Module size | 160mm(W) ×160mm(H) | |||||
Chip | R: Guanglei, G,B:Silan
| Pixel pitch | 10 mm | |||||
Brightness | ≥6000cd/ m² | Max power consumption | 1200 W/ m | |||||
Average power consumption | 600W/ m² | Life span | 100,000hour | |||||
Power supply | ||||||||
Input voltage | three-phase five-wire 380V | Output voltage | 220V | |||||
Electrical current | 50A | Power consumption | average:0.5wh/m² | |||||
Multi-media control system | ||||||||
Industrial PC | Processor: Dual Core CPU, display card: 512,hard disk:320G,CD-ROM:DVD, internal storage:2G | |||||||
Monitor | KVM 15-inch LCD display | Power amplifier | unilateral power output:200W | |||||
Speakers | Max power consumption:200W | Control system of LED screen | Linsn/ZHOGNQING(technology of point by point correction) | |||||
Optional Configuration | ||||||||
LED Screen | Could choose size of 4800mm×2400mm | |||||||
electrical equipment | Could choose touch touch panel,wireless,upper computer control system | |||||||
New Product Advantages of YES-TB16 Outdoor Mobile Led Advertising Vehicle:
