2013 Outdoor Advertising LED Truck YES-V6
1. Japanese Isuzu chassis ensures perfect mobility performance.
2. One side equipped with outdoor full color led display,Another side equipped with a LED strip screen and scrolling light box.
3. Built-in super quite generator and multi-media playing system
4. The mobile LED truck can be equipped with air-conditioner as your demand.
5. On-board panel control system, easy to operate and maintain.
Applications of 2013 Outdoor Advertising LED Truck YES-V6
1. Cruise show: Property market products cruise promotion, expos, fairs, large multi-stop cruises, company's annual cruise exhibition, etc.
2. Media: Fixed point outdoor advertising playing, public information transmission, and large mobile propaganda.
3. Activities: product promotion activities, client-side promotions, etiquette & public relations activities, brand promotion, talent show, product marketing show.
4. Live broadcast: large-scale sports events, domestic and overseas major events live broadcast/ retransmit vocal concert, concert, etc.
5. Ceremonies: house property opening, anniversary celebration, opening ceremony, festivals ceremony, ribbon-cutting ceremony, wedding, funeral, enterprise annual meetings, etc.
6. Exhibitions: large scale exhibitions, shows, etc.
Specifications of 2013 Outdoor Advertising LED Truck YES-V6
Model |
YES-V6 |
|
||||||||
Chassis |
|
|||||||||
Brand |
Brilliance JINBEI |
External dimension |
5459mm×1900mm×3200mm |
|
||||||
Power type |
CA4DC2-10E4 |
Curb weight |
1959KG |
|
||||||
Emission standard |
Euro IV |
Gross mass |
4450KG |
|
||||||
Maximum capacity |
Three people |
Wheel base |
3350mm |
|
||||||
Extreme super silent generator set |
|
|||||||||
External dimension |
510mm×900mm×1060mm |
Power |
7.5KW |
|
||||||
Power type |
Kipor |
Number of cylinders |
Water-cooled inline 3-cylinder |
|
||||||
Air displacement |
1.995L |
Bore x Stroke |
84mm x 90mm |
|
||||||
Full Color LED Display |
|
|||||||||
LED Screen size (P10) |
3840mm×1920mm |
Module Size |
160mm(W) ×160mm(H) |
|
||||||
Chip |
R: GUANGLEI; G,B: SILAN |
Pixel pitch |
10 mm |
|
||||||
Brightness |
≥6500cd/m² |
Max power consumption |
1000 W/m² |
|
||||||
Average power consumption |
500W/ m² |
Life span |
100,000 hours |
|
||||||
LED bar screen |
|
|||||||||
External dimension |
3840mm×480mm |
Pixel pitch |
10 mm |
|
||||||
Tube core |
GUANGLEI(R) |
Module resolution |
32pixel(W) ×16pixel(H) |
|
||||||
Scrolling Light box |
|
|||||||||
Display size |
3250mm×1550mm |
Roller diameter |
80 mm |
|||||||
Motor power |
≥80W |
Control mode |
Intelligent remote control |
|||||||
Power supply |
|
|||||||||
Input voltage |
three-phase five-wire 380V |
Output voltage |
220V |
|
||||||
Electrical current |
50A |
Power consumption |
Average: 0.5wh/m² |
|
||||||
Multi-media control system |
|
|||||||||
Industrial PC |
Processor: dual core CPU; display card: 512; hard disk: 320G; CD-ROM: DVD; storage card: 2G |
|
||||||||
Monitor |
15-inch Industrial Display |
Power amplifier |
unilateral output power: 200W |
|
||||||
Speakers |
Max power consumption:200W |
Control system of LED screen |
LINSN/ZHOGNQING |
|
||||||
Outer frame and inner decoration |
|
|||||||||
Cold rolled metal plate of Outer box |
1.5mm |
Surface car baking varnish |
Polar White |
|
||||||
Inner decoration |
Fire Retardant Board |
Waterproof processing |
Vehicle plastic irrigation processing |
|
||||||
Optional Configuration |
|
|||||||||
LED screen |
option: P7.62 LED full color screen |
Air-condition |
Option: Vehicle mounted air-conditioner |
|
||||||
Electric control system |
option: Touch type wireless remote control |
Video system center |
Option: 1 set Video Processor |
|
||||||
