Leading Manufacturer & Solution Provider of Mobile LED Advertising Vehicles
1. LED Screen: It uses imported EPISTAR chips, high level of illumination, long life-span, and high refresh frequency and easy to maintain.
2. Chassis brand: ISUZU, meets Euro IV emission standard, original imported motor(low noise, fuel efficient ). The cockpit is equipped with air conditioning, CD player, FM and so on.
3. Generator set: It is specialized designed for YEESO. Lower noise and stable.
4. Lifting system of LED screen: We use the electric puts as the lifting system, since the synchronization error of two Electric puts is only 1mm.
5. Vehicle air-conditioner: Its most important function is cooling the LED screen and the generator, also it could well cool the carriage, and provide a very comfortable environment for the staffs. The vehicle air- conditioner also has excellent quake-proof index and waterproof index.
6. Multi-media Control System: Integrated control cabinet with industrial computer, amplifier, and operation buttons together. The speakers are equipped in the frame of carriage. With it, you could do on-site live recording and broadcasting, television program broadcasting, live karaoke and so on.
7. Interior space optimization: We offer a free space of 1.6 m × 4.8 m in the carriage. So customers could use it as a reception room, a showroom, or a dressing room and so on.
8. Two sides LED screens or three sides LED screens are optional.
Overall Description | |||
Chassis Brand |
ISUZU |
External Dimension |
7935mm x 2300mm x 3800mm |
Emission Standard |
Euro IV |
Gross Mass |
9030kg |
Hydraulic Lifting & Supporting System | |||
Lifting System for LED Screen |
Electric putt. Lifting height: 2000mm, afford 3T, Synchronous error: 1mm |
Supporting System |
Hydraulic cylinder. Lifting height: 300mm, each afford 5T, wind-proof level can reach to max level 8 |
Extreme Super Silent Generator Set | |||
Dimension |
1510mm x 900mm x 1060mm |
Power |
16KW |
Motor Type |
Extreme super silent type |
Air Displacement |
1.995L |
LED Display System | |||
LED Screen Size |
4800mm x 2400mm |
Module Size |
160mm(W) x 160mm(H) |
Chip |
R,G,B: EPISTAR |
Pixel Pitch |
10mm |
Brightness |
≥6500cd/ m² |
Life Span |
10,000.00h |
Average Power Consumption |
500W/ m² |
Max Power Consumption |
1200W/ m² |
Rear Screen Size |
1220mm x 1952mm(SMD) |
Chip |
R,G,B: EPISTAR |
Module Size |
244mm(W) x 122mm(H) |
Pixel Pitch |
7.62mm |
Red Color LED Size |
5440mm x 480mm |
Pixel Pitch |
10mm |
Chip |
R,G,B: EPISTAR |
Module Resolution |
32pixel(W) x 16pixel(H) |
Scrolling Light Box | |||
Display Size |
3900mm x 1500mm |
Roller Diameter |
100mm |
Motor Power |
≥80W |
Control Mode |
Intelligent remote control |
Outer Power Supply | |||
Input Voltage |
AV380/50A |
Output Voltage |
AC220V |
Multi-media Control System | |||
Industrial PC |
Processor: Dual core CPU, Display card: 1G, Hard disk: 500G, CD-ROM: DVD, Internal storage: 2G |
Monitor |
15-inch LCD display |
Power Amplifier |
Unilateral output power: 200W |
Speaker |
Max power consumption: 200W |
Control System of LED Screen |
LINSN |
|
|
Outer Frame and Inner Decoration | |||
Frame Material |
1.5mm cold rolled metal plate |
Surface Color |
Pure white car baking varnish |
Inner Decoration |
Fire retardant board |
Water-proof Processing |
Vehicle plastic irrigation processing |
Vehicle-Specified Air Conditioner | |||
Cooling Power |
4000W |
Heating Power |
1600W |
Instillation |
Overhead |
Applying Space |
15m³ |
