Mobible Road Show Truck Mobile Road show van
1. It can be mounted on a truck chassis
2. It's use for Outdoor Ad, Road Show, Promotion Activities
Mobible Road Show Truck Mobile Road show car
YES-C40 Technical parameters
Model |
YES-C40 ( Truck Chassis excluded) |
|||
Trailer Chassis(50#) | ||||
Brand |
SCGC |
External dimension |
13000mmx2550mx3900mm |
|
Curb weight |
23000KG |
Gross mass |
23000KG |
|
Hydraulic Lifting & Supporting System | ||||
Hydraulic lifting system |
Hydraulic lifting system; Lifting height: 1800mm |
|||
Hydraulic supporting system |
It can goes up 800mm,each afford 10T,its wind-proof level can reach to maximum level 8 when screen is lifted up |
|||
Extreme Super Silent Generator Set | ||||
External dimension |
1510mm×900mm ×1060mm |
Power |
16KW |
|
Power type |
KIPOR |
Number of cylinders |
Water-cooled inline 4-cylinder |
|
Air displacement |
1.995L |
Bore*stoke |
84mm×90mm |
|
LED screen | ||||
Main Screen size |
5120mm×2240mm |
Module size |
320mm(W) ×320mm(H) |
|
Chip |
R,G,B; EPISTAR |
Pixel pitch |
8mm |
|
Brightness |
≥6500cd/m² |
Max power consumption |
1200W/m² |
|
Power consumption |
Average: 500W/m² |
Life span |
100,000hours |
|
Power Supply | ||||
Input voltage |
Three phases, five wiring , 380V |
Output voltage |
220V |
|
Electrical current |
50A |
Power consumption |
Average:0.5wh/m² |
|
Multi-Media Control System | ||||
Industrial PC |
Processor:Dual Core CPU; PCI-E:1G; Hard disk:500G; CD-ROM: DVD; Memory:2G |
|||
Monitor |
KVM 15-inch LCD display |
Power amplifier |
unilateral power output:200W*2 |
|
Speakers |
Max power consumption:200W×4 |
Control system of LED screen |
LINSN (technology of point by point correction) |
|
Outer Frame and Inner Decoration | ||||
Material |
Cold rolled metal plate |
Surface car baking varnish |
pure white |
|
Inner decoration |
Fire Retardant Board |
Waterproof processing |
Vehicle plastic irrigation processing |
|
Stage On board | ||||
Stage Size |
9mx3.5m |
Loading Capacity |
150kg/m² |
|
Vehicle Specified Air Conditioner |
4000w(cooling)/1600w(heating) |
Video Processor |
Video Processor for Live Broadcast |
|
