4 Post Car Parking Lift, 4 Columns Stacker Car Lift With CE, Good Quality Low Price Car Park Lift

4 Post Car Parking Lift, 4 Columns Stacker Car Lift With CE, Good Quality Low Price Car Park Lift thumbnail-1
4 Post Car Parking Lift, 4 Columns Stacker Car Lift With CE, Good Quality Low Price Car Park Lift photo-1
US$ 1,380 - 1,570 MOQ: 12 Sets
Key Specifications
Get Latest Price
Type:
Parking Lift
Height (mm):
1800
Width (mm):
2086
Contact Supplier Request Quote Chat Now
Qingdao Telian Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Parking Lift
Height (mm) 1800
Width (mm) 2086
Place of Origin Shandong, China
Brand Name TELIAN
Model Number PTJ601
Warranty 12 Months

Specifications

family parking lift, garage parking, 2 cars parking, 3mt loading, easy parking, 4 post parking lift. best quality low price four

Characteristics

1. Hydraulic drive, steel rope lift, hydraulic system makes the system very low noise and steady working;

2. Single unlocked by manual or four sides unlocked automatically with anti-fall devices; the anti-fall blocks installed in the columns will prevent the car platform to fall informally to insure safety of the car;

3. Self-lubrication bearing to guarantee the safety at any height;

4. Slippery runways and the traction plate for convenient use; the distance between two runways plates are fixed, there is movable plate to receive oil in the middle;

5. Appearance with high quality painting, green environment protection without lead, beautiful color, anti-rust painting for long time use;

6. This park lift is convenient and reliable, easy operation, quick installation, simple installation at site, no welding, no cutting, low requirements of land area; and it is movable, easy re-installation to adapt all sites;

7. Lift weight can reach 3mt for double cars parking;

8. Adaptable at family garage with a parking space L5.2m, W2.7m, H3.6m;



Parameters of this Park Lift

Noise: 75dB max;                 Lift time: 60S

Fall time: 90S                    Max lift weight: 3mt

Max lift height: 1800mm                Height of system:  2086mm

Central column width: 2353mm     Distance of runway plates: 949.5mm

Motor power: 2.2kw                       Voltage: 220V/380V

Work pressure: 14Mpa                    Unlocked style: Manual/Auto

 4 post car parking lift, 4 columns stacker car lift with CE, Good quality low price car park lift

Description

This park lift can be used for family, apartments, hotels and other places; it can be designed based on site dimensions; 1 car space will park two cars to save more spaces; it can be installed both inside room and outside; For family use, it can provide 220V power; it can be used both for parking and repairing cars; Special-made for SUVs OK.



Appearance and coating

1. Painting

2. Hot galvanizing, Price will be USD160 more than ordinary painting;



Structures: Composed of steel frame, transmission system, pallet, safety protection devices, electric control system and operation system;
