Product Description
— • — • — • — — • — • — • — — • — • — • — — • — • — • —
Product Description:
1. Save land area and take full use of space and columns can be arranged according to your requirements.
2. Adopt PLC automatic control system, use button, IC card and remote control system, make operation very easy.
3. Each system in the parking spaces are only on the operation box, press the button, the corresponding parking the vehicle automatic arrangement, adjust to the best position, so that the vehicle access; two layer of parking equipment access vehicle as an example process is as follows: The ground floor car parking direct access; The two floor parking access to the car, the ground floor car move towards the two sides make room, two parking spaces down to a layer, can be out of the car.
4. Vehicle loading pallet fully enclosed design, to avoid oil leakage, rain and snow.
5. Spraying plastics, high anti-corrosion ability. Electrical and driving parts with water proof characteristics.
6. Simple structure, easy installation, minimal requirements for civil engineering.
PSH2F:
Item |
Unit |
Technical parameters |
|
Specification |
L×W×H |
mm |
5000×1850×1550 |
Weight |
kg |
2nd level: ≤1750 |
|
1st level: ≤2000 | |||
Parking capacity |
2N(column) -1 |
||
Rated speed |
Lifting |
m/min |
4~5 |
Sliding |
m/min |
7~10 |
|
Engine power |
Lifting |
|
2.2 |
Sliding |
|
0.2 |
|
Mode of drive |
Wire rope, chain |
||
Control mode |
PLC program control |
||
Mode of operating |
Button, touch screen, IC card (alternative) |
||
Electricity |
3N, AC, 380V, 50Hz |
||
|
|
ehicle loading pallet fully enclosed design, to avoid oil leakage, rain and snow.
Packaging
— • — • — • — — • — • — • — — • — • — • — — • — • —
1.All structures fixed on the frame by screws.
2.All electric wires and motor put into carton.
3.Each package will twine three stretch film to prevent water.
4.During the unloading,please use forklift to unload the iron frame.
Service— • — • — • — — • — • — • — — • — • — • — — • — •
We will strain every nerve to do after sale service for you .In order to allow you to get more efficient ,more satisfied with the services,our company has made the following commitements:
1. Our company promises "custormer satisifaction" ;
2.Failure occurred in the process of equipment operation ,customer service staff received the user"call to repair the "notification,immediately rushed to the scene, get rid of failure and treatment;
3.Adequate spare parts,in case of failure to ensure the timely replacement;
4.Our company has a product liability insurance with the PICC,to provide security;
6.Our company will be professional ,the customer product structure and detailed maintenance training,to ensure that customers buy without worry ,worry free.
