digital thermostat STC-200

STC-200 alarm temperature controller

Introduction:


Suitable for all kinds of high temperature cold storage, direct cooling cabinet, water chiller, seafood machine and some small heating equipments etc.

Features:

1. Refrigerating, heating, alarming modes optional
2. Return difference to control temperature
3. User menu and administrator menu setting separately
4. Temperature upper and lower limits setting, in order to avoid disoperation by non-professionals.

Main Function:

Refrigeration,heating,Alarm 1NTC,Temperature Calibration

Parameter:

1. Power supply: 220VAC±10%, 50/60HZ (12VAC/VDC,optional)
2. Temperature measuring range: -40~+99°C
3. Temperature controlling range: -40~+70°C
4. Resolution: 1
5. Accuracy: ±1°C
6. Compressor output contact capacity: 7A/220VAC
7. Sensor type: NTC, 2M
8. Alarming: buzzer or alarm relay
9. Shell: gray ABS flame retardant material
10. Safety level: IP54 (front panel)

Specifications:

Mounting size: 71(W) * 29(H) (mm)
Product size: 75(W) * 34.5(H) * 65.5(D) (mm)
