Automatic Car Washing Machine Two Post Car Lift 4.2 T
- Qingdao
You May Like
Product Details
| Type | Parking Lift | Height (mm) | 3446 | |
| Width (mm) | 2777 | Place of Origin | Shandong, China | |
| Brand Name | TELIAN | Model Number | QTL0209 | |
| Warranty | 1 Years |
Product Description
Specifications
Two Post Car LiftEasy to operate
Automatic stop bar
Automatic arm unlocking
Lifting fast,high-pressure c
2 Post Car Lift
Drawing
Technical parameter
Model No. | Lifting capacity | Lifting height | Overall height | Width between posts | Rise/drop time | Power |
QTL0207 | 3200kgs/7000lbs | 1800mm | 3620mm | 2777mm | 50/40s | 2.2KW |
QTL0209 | 4200kgs/9000lbs | 1800mm | 3622mm | 2777mm | 50/40s | 2.2KW |
Features:
- Easy to operate
- Dual-cylinder two post
- Automatic stop bar
- Automatic arm unlocking
- Lifting fast,high-pressure cylinder
- Cable-equalization system
- Low energy consumption,low operational noise volume
- Automatic stop in the highest position
- Extra width between posts,no floor plate
- Long life hydraulic power unit
- Triplicate safety locks
- Plastic powder coat finish
Technical parameter
Working noise : ≤ 75dB ( A )
Rise time : 50s
Drop time : 40s
Working temperature : -5 °C~ 40 °C
Motor power : 2.2Kw/220 ~ 380V
Working pressure : 14Mpa
relative humidity : 80%
Using altitude : ≤ 1000m
lifting capacity : 7000lbs/3200kgs
Lifting height : 1800mm
width between post : 2777mm
Whole height : 3620mm
Package size : 1070 × 500 × 3740mm
20 container : 14 sets
40 container : 36 sets
