Roofing Waterproof Material SBS Membrane With Color Granules

Name: Roofing Waterproof Material SBS Membrane With Color Granules
Brand: ALLIPH
SKU: 115182285
Availability: InStock

US$ 4 - 5 MOQ: 4000 Square Meters

Key Specifications

Place of Origin:

Tianjin, China

Brand Name:

ALLIPH

Model Number:

SBS rolls

ALLIPH (Tianjin) Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xingang

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Tianjin, China

Brand Name ALLIPH

Model Number SBS rolls

SBS Membrane with Color Granules

Product Description

Technical Data

ITEM			INDEX
			Ⅰ		Ⅱ
			PY	G	PY	G	PYG
Solvent Content (g/m2)≥	3mm		2100	2100	2100	2100	-
	4mm		2900	2900	2900	2900	-
	5mm		3500	3500	3500	3500	3500
	Test phenomenon		-	The mat not burning	-	The mat not burning	-
resistance to heating	℃		90	90	105	105	105
	≤mm		2	2	2	2	2
	Test phenomenon		No flow, drippage	No flow, drippage	No flow, drippage	No flow, drippage	No flow, drippage
low temperature flexibility/℃			-20	-20	-25	-25	-25
low temperature flexibility/℃			no crack	no crack	no crack	no crack	no crack
waterproof 30min			0.3Mpa	0.2Mpa	0.3Mpa	0.3Mpa	0.3Mpa
Tension	Max/(N/50mm)≥		500	350	800	500	900
	Second(N/50mm)≥		-	-	-	-	800
	Test phenomenon		in middle of the test piece, the bitumen coating no crack or separate from the mat
Extensibility	Max/%≥		30	-	40	-	-
Extensibility	Second/%≥		-	-	-	-	15
Weight adding after dipping/%≤	PE,S		1.0	1.0	1.0	1.0	1.0
Weight adding after dipping/%≤	M		2.0	2.0	2.0	2.0	2.0
Heating aging	tension holding/%≥		90	90	90	90	90
	extensibility holding/%≥		80	80	80	80	80
	low temperature flexibility/℃		-15	-15	-20	-20	-20
	low temperature flexibility/℃		no crack	no crack	no crack	no crack	no crack
	dimension changing/%≤		0.7	-	0.7	-	0.3
	loss of weight		1.0	1.0	1.0	1.0	1.0
Oil penetration	Pcs ≤		2	2	2	2	2
Joint peeling strength/(N/mm)≥			1.5	1.5	1.5	1.5	1.5
Nail bar tear strength a/N≥			-	-	-	-	300
Mineral grain adhesion b/g≤			2.0	2.0	2.0	2.0	2.0
Lower surface bitumen coating thickness c/mm≥			1.0	1.0	1.0	1.0	1.0
Artificial weathering		appearance	No sliding,flow and dripped
		tension holding/%≥	80	80	80	80	80
		low temperature flexibility/℃	-15	-15	-20	-20	-20
		low temperature flexibility/℃	no crack	no crack	no crack	no crack	no crack
