Cheap CNC Mechanic Turret Punch Machine

Cheap CNC Mechanic Turret Punch Machine photo-1
US$ 50,000 - 60,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
Almaco
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Jiangsu, China
Brand Name Almaco
Model Number HP-M300
Machine Type Other, Punch machine
Raw Material Sheet / Plate Rolling
Material / Metal Processed Stainless Steel
Power Cnc
Automation Automatic
Extra Services Other, bending
Certification CE
After-sales Service Provided Engineers available to service machinery overseas



Product Description





Cheap CNC Mechanic Turret Punch machine

cheap CNC Mechanic Turret Punch machine

HP-M300 CNC Turret Punch Machine

The high precision large traverse ballscrews and linear guideways with reliability are equipped for driving
The reliable national level CNC systems is fitted with the machine.
To make the machine more reliable, the import cluch is used.
The main pneumatic parts are imported name ones to make the mechanism more reliable.
The fully bushed high precision turret improves efficiently the accuracy and longevity of the turret, and the 24 or 32 stations is optional.
The advanced working and heat treatment technology is adopted to the tools for the longevity of the tools

Tooling layout




Stations number
Tooling diameter rang
Tooling number
24 stations
Φ88.9-Φ32
Φ7/2-Φ5/4
4
32 stations
Φ32-
Φ5/4
20
Φ88.9-Φ32
Φ7/2-Φ5/4
4

Φ32-
Φ5/4
28








Specification
Unit
HP-M300
punch force
KN
KN
300
300
Max. sheet working size
mm
in
1250 x 2500
50 x 100
Max. sheet working welth
kg
lb
150
330
max. sheet thickness
mm
in
6.35
0.254
Max. Punch diameter
mm
in
Φ88.9
Φ3.56
Number of tool stations


24, 32
24, 32
Positionzing repetability
mm
in
0.1
0.004
Max. hit speed
hpm
hpm
300
300
Pax. traversing speed
m/min
in/min
56
2240
Turret rotation
rpm
rpm
30
30
Axis number


3
3
Compressed air pressure
mpa
mpa
0.6
0.6
Shipping dimensions
mm
in
500 x2680 x2175
20x107.2 x87
Machine weight
ton
lb
13
28600



 machine process:

cheap CNC Mechanic Turret Punch machine



Packaging & Shipping



The machines are packed with wooden case or depend on your requires.

Regarding to the shipping, the machine will be deliveried to your destination ports or place you assign





Our Services



1.OEM



2.Spare parts



3.Warranty for one year



4.Tech support is available for 24 hours



5.Fast delivery





Company Information



Found in 1984 Our Almaco Machine Tool Co., Ltd as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation. specializes in import& export of brand-new industrial machinery & tools. Our mechanical products cover more than 80 kinds including lathe, milling machine, grinding machine, power press, hydraulic guillotine, hydraulicpress brake, CNC & automotive machines and so on, which have been exported to 50or more countries & areas.
 Almaco Machine Tool Co., Ltd is proud to be the professional, high reputation company with high-qualified & professional staff, competive prices and quick & thoughtful after-sale service to cooperate with you.









CERTIFICATION:



customer visiting:





cheap CNC Mechanic Turret Punch machine

Our products are exported to more than 50 countries, more than 700 customers











FAQ



1. Accept L/C, T/T  ,D/A,D/Ptype of payments



2. Regarding to the technical questions, pls contact our R&D



3. Any question, call us or send email, we will try our best to satisfy you
