universal vertical and horizontal milling machine TMN6330H
Standard Equipment
Electro cabionet and hung up control panel
Electro lubricate pump
Working lamp
Knee rapid elevationg motor
Draw bar Plastic splashing guard
Cooling system
Oil collecting plate
Leveling wedge screw
universal vertical and horizontal milling machine TMN6330H
universal vertical and horizontal milling machine TMN6330H
| Model | Unit | TMN6330H | TM6330H | TMS6330H | |||
| Table size | mm | 300 x 1300 | 300 x 1300 | 300 x 1500 | 300 x 1370 | 300 x 1500 | |
| Table longitudinal travel (manual) | mm | 845 | 845 | 1000 | 800 | 1000 | |
| Table cross travel (manual) | mm | 385 | 385 | 385 | 380 | 380 | |
| Knee vertical travel (manual) | mm | 435 | |||||
| Table longitudinal feed rate | mm/min | 0-3500 Servo Motor |
|||||
| Table cross feed rate | mm/min | ||||||
| Knee rapid speed | mm/min | 900 | |||||
| Vertical Speedle |
Motor power | HP | 5HP | 3HP/OPT.5HD | |||
| Speed | rpm | (Standard: 16 steps): 50HZ: 65-4500/HZ: 80-5440 (Optional: variable speed): 65-3750 |
|||||
| Taper | ISO40 | standard:R8/OPT.ISO40 | |||||
| Quill travel | mm | 127 | |||||
| Quill feed | mm/rev | 0.04/0.08/0.15 | |||||
| Head rotating | (R/L) 90° | ||||||
| Distance from spindle end to table surface | mm | 115-545 | |||||
| Horizontal spindle |
Motor power | HP | 5HP | ||||
| Spped | rpm | 50HZ: 45/80/165/260/500/980 60HZ: 55/100/200/315/600/1180 | |||||
| Taper | ISO40 | ||||||
| Distance from spindle center to table surface | mm | 20-410 | |||||
| Distance from spindle center to ram | mm | 183 | |||||
| Ram travel | mm | 480 | |||||
| Ram rotating | 360° | ||||||
| Net weight | kg | 1900 | 1900 | 1950 | 1680 | 1730 | |
| Package size (L x W x H) | cm | 180 x 150 x 220 |
180 x 150 x 220 |
180 x 150 x 220 |
180 x 160 x 220 |
180 x 180 x 220 |
|
Our service:
1,Your inquiry will be replied in 24 hours.
2.Our manufacture/company has been a Gold supplier continuously in this Alibaba website for 6
years.And there is more industry technology experience for 20 years with our manufactures
3.To offer free spare parts and service within one year of warranty
4.Technology Support Provide operation video for training
5.Professional after-sales service team
6.Give reasonable offers with the best quality
Our advantage:
1,More then 20 years experience for indusry product
2,All modles with CE,TUV,SGS,ISO9001/9002 or other authority approved
3,Professional service and technology
4,Excellent reputation all over the world
5,Final exported producuts would pass strict test by international authority BIVAC
6, There is more exporting experience for 20years with our owned manufacture/company
Welcome to Almaco Machine Tool Co., Ltd
our company as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation,specializes in import & export of brand-new industrial machinery & tools.Our mechanical products with ISO9001 or CE certificate cover more than 80 kinds including lathe ,milling machine,grinding machine,power press,guillotine shearer,hydraulic press brake,CNC Machine and so on,which have been exported to 40 or more countries & areas.
We are looking forward to bulding sincere and long-term business relationship with you
