new type milling machine USM32C*16
Standard Accessories
Dividing head
Rotary table
Boring head
Transmission box
Milling chuck
Machine vise etc
new type milling machine USM32C*16
new type milling machine USM32C*16
| MODEL | USM32B | USM32C | USM32 x 16 | USM32C x 16 | |
| Table area (width x length) | mm | 320 x 1320 | 320 x 1320 | 320 x 1600 | 320 x 1320 |
| T-slots (No.-width x pitch) | mm | 3-18x70 | 3-18x70 | 3-18x70 | 3-18x70 |
| Table Travel (manual) X/Y/Z | mm | 700/255/320 | 700/255/320 | 700/255/320 | 700/255/320 |
| Table travel (power) X/Y/Z | mm | 680/240/300 | 680/240/300 | 700/240/300 | 700/240/300 |
| Table Swivel degree | +45° | +45° | +45° | +45° | |
| Vertical Milling head swivel degree | 360° | 360° | 360° | 360° | |
| Max weigh of workpiece | kg | 500 | 500 | 500 | 500 |
| Spindle motor power (horizontal/vertical head) | kw | 5.5/3 | 5.5/3 | 5.5/3 | 5.5/3 |
| Spindle taper (horizontal/vertical head) | 7:24 50#/40# | 7:24 50#/40# | 7:24 50#/40# | 7:24 50#/40# | |
| Spindle speed range (horizontal/vertical head) | r/min | 18 30-1500/90-1400 |
18 30-1500/125-2000 |
18 30-1500/90-1400 |
18 30-1500/125-2000 |
| Feed speed (X/Y/Z) | mm/min | 18 23.5-1180/ 23.5-1180/8-394 |
18 23.5-1180/ 23.5-1180/8-394 |
18 23.5-1180/ 23.5-1180/8-394 |
18 23.5-1180/ 23.5-1180/8-394 |
| Rapid speed (X/Y/Z) | mm/min | 2300/2300/770 | 2300/2300/770 | 2300/2300/770 | 2300/2300/770 |
| Distance from center line of horizontal spindle to table surface | mm | 30-350 | 30-350 | 30-350 | 30-350 |
| Distance from vertical spindle nose to table surface | mm | 40-425 | 250-570 | 40-425 | 250-570 |
| Feed motor power | kw | 1.5 | 1.5 | 1.5 | 1.5 |
| DRO Resoluction (DRO milling machine only) | mm | 0.005 | 0.005 | ||
| Machine dimensions (L x W x H) | mm | 2294x1770x1858 | 2294x1770x1858 | 2294x2045x1858 | 2294x2045x1858 |
| Weight of machine (about) | kg | 3000 | 3000 | 3000 | 3000 |
Our service:
1.All of our goods will pass QUALITY INSPECTIONS before shipment.Best after sale service, customer can follow their order sit uation any time, no matter on product line, warehouse or shipment.
2.More than 10 years experience in exporting to make your order more smooth.Less than one container loading is accepted.
On time delivery, in general 30 days. Multimode payment:T/T,L/C.
3.Special dimensions available according to request.
4.We have many certificates of our Products.
5.Accessories replacement if our product itself has quality problems during one year after receiving.
Welcome to Almaco Machine Tool Co., Ltd
our company as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation,specializes in import & export of brand-new industrial machinery & tools.Our mechanical products with ISO9001 or CE certificate cover more than 80 kinds including lathe ,milling machine,grinding machine,power press,guillotine shearer,hydraulic press brake,CNC Machine and so on,which have been exported to 40 or more countries & areas.
We are looking forward to bulding sincere and long-term business relationship with you
