chinese CNC engraving machine A750
The A series adopts 5.5Kw electrical spindle up to 24000rpm.
Three axes with strong feed torque, large stroke and heavy load, it can mill and engraving, suitable for small parts machining.
Castings are made through resin sand molds. Pass the multi-step aging to relieve the internal stress of the castings and to ensure the machining accuracy.
The structure of the machine tool is optimized by finite element analysis to get the best rigidity and stability.
High density material has good shock absorbing and stability. The worktable moves smoothly and stable in heavy cutting.
Three axes configured high precision linear guides, It is high rigidity, low noise and low friction thus the axes moves fast and accurate.
Three axes adopt high torque and high precision ball screws with NSK TAC series bearings. The ball screws are pre-load to keep precision from heat when rotating fast.
Axes are driven by powerful AC servo and transfer by Germen R+W high torque coupling. The great feed power, high response and excellent cutting performance are archived.
Three axes are lubricated by thin oil. Adopt detective volue lubricate system, fed by accurate oil distribution indirectly. The distributor allows for visible observation of the operation condition providing easy preservation and maintenance.
The nice sheet metals are painted by imported paint. Lambdoidal guards provide good protection from chips.
chinese CNC engraving machine A750
chinese CNC engraving machine A750
| model | A545 | A650 | A750 | |
| Column Space | mm | 575 | 640 | 660 |
| Worktable | mm | 550x480 | 600x540 | 800x600 |
| X/Y/Z Stroke | mm | 450x500x250 | 500x600x250 | 600x700x350 |
| Distance from spindle to Table | mm | 70-320 | 70-320 | 80-430 |
| Worktable T-slot | mm | 3-16x150 | 5-16x100 | 5-16x150 |
| Max Load on Table | kg | 250 | 300 | 400 |
| Rapid Feed Speed | m/min | 24 | 24 | 24 |
| Max Cutting Feed Speed | m/min | 12 | 12 | 12 |
| Servo Motor Torque | NM | 5.5 | 5.5 | 5.5 |
| Spindle Speed | RPM | 18000/*24000 | 18000/*24000 | 18000/*24000 |
| Spindle Specifications | mm | ER25/*BT30 | DR25/*BT30 | ER25/*BT30 |
| Spindle Motor Power | KW | 5.5 | 5.5 | 5.5 |
| Machine Weight | T | 2.5 | 2.8 | 3.7 |
| External Dimension | mm | 1720x1600x2100 | 1800x1700x2200 | 2370x1900x2300 |
Welcome to Almaco Machine Tool Co., Ltd
our company as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation,specializes in import & export of brand-new industrial machinery & tools.Our mechanical products with ISO9001 or CE certificate cover more than 80 kinds including lathe ,milling machine,grinding machine,power press,guillotine shearer,hydraulic press brake,CNC Machine and so on,which have been exported to 40 or more countries & areas.
We are looking forward to bulding sincere and long-term business relationship with you
The machines are packed with wooden case or depend on your requires.
Regarding to the shipping, the machine will be deliveried to your destination ports or place you assign
Our engineer team
*******************************************************************************************************
1.All of our goods will pass QUALITY INSPECTIONS before shipment.Best after sale service, customer can follow their order situation any time, no matter on product line, warehouse or shipment.
2.More than 5 years experience in exporting to make your order more smooth.Less than one container loading is accepted.
On time delivery, in general 30 days. Multimode payment:T/T,L/C.
3.Special dimensions available according to request.
4.We have many certificates of our Products.
5.Accessories replacement if our product itself has quality problems during one year after receiving.
